MPPT charge controller User Manual
2
>Para_Mode
Display Setting range Description
OutCtrl_CHG
0- Disable
1- Enable
Default setting: 0-Disable
Enable state of charging
external control mode,
read only.
RlyCtrl_Config
0-Default
1- Alarm Switch
Default setting: 0- Default
Output dry contact
configuration.Select 0, if
the connection is detected
in the DC Coupling
system
, take one puff
every 5 minutes to wake
up Kinergier
Pro(Connected to the
input dry contacts of the
Kinergier Pro).
Select1,short connection
at fault alarm.
Silent_Mode_EN
0- Disable
1- Enable
Default setting: 0-Disable
Silent mode setting
Force_Charger
0- Disable
1- BAT_Level_12
2- BAT_Level_24
3- BAT_Level_48
Default setting: 0-Disable
Forced charge mode
setting
EPO_DRY_IN_EN
0- Disable
1- Enable
Default setting: 0-Disable
Remote Switch enable
setting
Under the Setting menu, there are three parameter Setting options, among which
EQ Setting needs to select the corresponding battery type to open.
>Basic Set
Advanced Set
>EQ Setting
In Basic Set, there are the following Setting options.
Display
Setting range
Description
