TC Electronic Helix Phaser User Manual

Setup
Helix Phaser English manual 2015-04-27 12
Ready…
Your TC Electronic effect pedal box should con-
tain the following items:
►
Your TC Electronic effect pedal
►
1 USB cable (Type A to Mini-A)
►
1 TC Electronic sticker
►
1 leaflet about TC’s guitar FX product range
Inspect all items for signs of transit damage. In
the unlikely event of transit damage, inform the
carrier and supplier.
If damage has occurred, keep all packaging, as
it can be used as evidence of excessive handling
force.
Set…
►
Connect a 9V power supply with the follow-
ing symbol to the DC input socket of your TC
Electronic effect pedal.
This product does not come with a power
supply. We recommend using TC Electronic’s
PowerPlug 9 (sold separately).
►
Plug the power supply into a power outlet.
►
Connect your instrument to the in jack on the
right side of the pedal using a ¼“ jack cable.
►
Connect the out jack on the left side of the
pedal to your amplifier using a ¼“ jack cable.
Play!

TC Electronic Helix Phaser Specifications

General

Product type	Pedal
Product color	Yellow
Built-in display	No
Manual	Yes

Weight and Dimensions

Depth	122 mm
Width	72 mm
Height	50 mm
