INPUT MODE SWITCHES:
STEREO INPUT: Disables the mix of inputs 1&2 to allow
stereo or separate input signals.
SEPARATE INPUT: Divides TC 1210 into two separate
mono in/stereo out chorus/flangers.
LINK MODE SWITCHES:
CROSS OFF: 1. IN NORMAL MODE:
Switches off the cross mixings of the channels.
2. IN SEPARATE MODE:
Disables the bypass link of the two channels.
SWEEP SYNC.: 1. IN NORMAL MODE:
Synchronizes the two LFO delay modulators in-phase.
2. IN SEPARATE MODE (and both channels on):
Mixes the LFO delay modulators of the two channels.
REAR PANEL CONTROLS & CONNECTIONS:
IN 1: XLR balanced left (mono) input.
IN 2: XLR balanced right input.
OUT 1: XLR balanced left output.
OUT 2: XLR balanced right output.
INPUT 2: 1. IN NORMAL MODE:
Right Input.
2. IN SEPARATE MODE:
Channel 1 input.
INPUT 1: 1. IN NORMAL MODE:
Left input.
2. IN SEPARATE MODE:
Channel 2 input.
OUTPUTS 2: 1. IN NORMAL MODE:
Right output.
