4. Adjust both the INPUT SENS gain controls so that the (yellow) odB PPM led
flashes as input signal is provided, the red +3dB led should flash only on high
peaks of the input.
5. Set the desired sounds:
Start with the setting samples and build your own sounds from them. Effect 1
and 2 are indicated on with their LFO LED’s flashing red/green.
SETTING SAMPLES
1. SPATIAL EXPANDER
2. CHORUS I
3. CHORUS II
4. DOUBLER
5. FLANGER I
6. FLANGER II
7. DELAY PANNING
SOUND 1 2 3 4 5 6 7
CONTROL SETTINGS:
BYPASS ON ON ON ON ON ON ON
INTENSITY 3 6 6 3 5 3 6
MODE 1 2 2 1 3 4 1
SPEED - ,5 ,2 ,5 ,1 ,2 ,5
WIDTH 0 3 5 3 1,5 6 1
DELAY 6 4 6 6 4 6 6
STEREO (ON if input signals in stereo, OFF if in mono)
SEPARATE (used only when using 1210 as two independent choruses)
CROSS OFF ON ON
SWEEP SYNC ON
BYPASS ON OFF OFF OFF OFF OFF OFF
INTENSITY 6
MODE 1
SPEED -
WIDTH 0
DELAY 5
