Output connections, low level, unbalanced
Termination Jack (phone-plug) unbalanced
Output impedance 100 Ohm
Max. output signal, R1=10 KOhm +21dBm (25Vpp)
Channel seperation (at 1KHz, typ.) 70 dB
Differential delay 0.66 to 22 mS
Sweep range 30 times
Crossmix cancellations typ. 40 dB
LFO speed range 0.1 to 10 Hz
10 sec. to 0.1 sec.
(with EX. SPEED shorted) 50 sec. to 0.5 sec.
External speed control
Termination: (tip channel 1, ring channel 2) jack stereo plug for down shift of LFO
frequency by pedal control
or voltage control 0 to 10V
with a sensitivity of -2.13 volts/octave (no shift at 5V)
External bypass control
Termination: (tip channel 1, ring channel 2) jack stereo plug for control by shorting to
ground (=bypass, open circuit = effect on) or by logic control (0V=bypass, open
circuit or 10 to 20V = effect on)
Mains voltage VAC 200 to 240 or 100 to 120, selectable
power consumption 18W
Mains fuse, 110V 125 mA (T)
220V 63 mA (T)
Dimensions (WxHxD) 482x44x185 mm (19x1.75x7.3”)
Weight 3,5 Kgs.
SERVICE
Service schematics and adjustment procedures are available from our distributors
provided a signed “for service only” request is made on your studio/shop letterhead
paper.
The two delay cards are interchangeable and are available as service-cards only
(due to special trim-equipment needed to optimize performance).
Please contact your dealer for service instructions.
