OPERATIONAL DESCRIPTION
The TC 1210 has two general modes of operation:
1. Normal mode (stereo or mono input - stereo output)
2. Separate mode (2 separate channels each: mono input - stereo output)
1. In normal mode the TC 1210 is a two preset unit where the two presets can be
used singly or combined.
2. In separate mode the TC 1210 is divided into two independent chorus/flangers.
It is possible to link the LFO’s and the bypass of the two channels, thereby
enabling the TC 1210 to synchronize the effects used on different tracks or
instruments.
DESCRIPTION OF CONTROLS
FRONT PANEL CONTROLS:
BYPASS: Switches the effects in and out.
INPUT SENS.: Controls the headrooms of the channels.
Adjusts the input and the output level simultaneously,
automatically giving the TC 1210 an 1:1 input/output gain
ratio.
PPM METER: Shows the headrooms of the channels.
INTENSITY: effect MODE 1: Controls the amount of direct (clean) signal.
effect MODE 2: Controls the amount of effect signal.
effect MODE 3: Controls the amount of signal regenerated.
effect MODE 4: Controls the amount of inversed signal re-
generated.
SPEED: Controls the rate of sweep from one sweep every ten
seconds to ten sweeps every second.
WIDTH: Controls the depth of the delay modulation from o to 100%,
DELAY: Controls the length of the delay time from approx. 0.65 to 12
mS.
