IM-4055
Installation, Operation & Maintenance Manual
10
Figure 3. Remote Mounted Dial Wiring Diagram — 115 or 230VAC Single Phase
24 VAC
REMOTE DIAL (TCF)
2
3
1
115 OR 230 VAC
YELLOW BLUE
COM
0 - 10 V
24 VAC
BLACK
WHITE
GROUND
SIGNAL
CONTROL
LEADS
POWER
LEADS
MOTOR
BLUE
YELLOW
DISCONNECT
BOX
GROUND
BLACK
WHITE
FACTORY PROVIDED
FIELD INSTALLED
0-10V-IN
0-10V-COM
Note: Diagram refers to motors 67001701, 67001703, 67001704,
67001705, 67001715.
