Optional - Wall Mount Installation
Do not install the table stands if the TV is wall mounted.
115”
Purchase a compatible VESA wall mount
VESA 1000x600 (4 M8x16mm screws)
7
(Wall mount hardware and accessories are not included.)
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200x200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
Note: Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.
Exposure will damage the TV.
Warning: This product should only be mounted by a professional installer.
Wall mount bracket installation is complete.
Remove the 4 rubber caps from the left and right sides of the TV.
Remove the 4 screws from the back of the TV.
B
D
FE
Leave the TV on the bottom foam packaging.
A
No obstacles
within 30mm
of subwoofers.
Screw the VESA bracket tightly onto the back cover with 4
M8x16mm
VESA screws purchased with wall mount.
C
Install the 4 handles to the left and right sides of the TV.
Note: Install the handles into place to ensure stability.
To Next Page
