TCL 21M63S-NX56E User Manual

T8-21APAK-MA1 41-WJ0090-B00 WIREBAREJUMPER9MM J234;J221
T8-21APAK-MA1 41-WJ0095-B00 WIREBAREJUMPER9.5MM J403
T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM
R004;J220;J607;J606;J230;J237
;J201;J110
T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM
J101;J601;J238;J308;J109;J205
;J206;J225
T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM
J248;J247;J001;J207;J108;J246
;J911;J226
T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM J002
T8-21APAK-MA1 41-WJ0105-B00 WIREBAREJUMPER10.5MM J413
T8-21APAK-MA1 41-WJ0110-B00 WIREBAREJUMPER11MM J908;J407
T8-21APAK-MA1 41-WJ0115-B00 WIREBAREJUMPER11.5MM J916;J215;J219;J218;J217;J216
T8-21APAK-MA1 41-WJ0120-B00 WIREBAREJUMPER12MM J917
T8-21APAK-MA1 41-WJ0125-B00 WIREBAREJUMPER12.5MM
J210;J204;J404;J608;J906;J203
;J811;J304
T8-21APAK-MA1 41-WJ0125-B00 WIREBAREJUMPER12.5MM J240;J241
T8-21APAK-MA1 41-WJ0150-B00 WIREBAREJUMPER15MM J006;J211;J224;J918
T8-21APAK-MA1 41-WJ0170-B00 WIREBAREJUMPER17MM J905
T8-21APAK-MA1 41-WJ0175-B00 WIREBAREJUMPER17.5MM J402;J406;J408
T8-21APAK-MA1 41-WJ0185-B00 WIREBAREJUMPER18.5MM J213
T8-21APAK-MA1 41-WJ0200-B00 WIREBAREJUMPER20MM J405
T8-21APAK-MA1 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM
FOR L458;FOR L451;FOR
Q402A;FOR T401
T8-21APAK-MA1 66-343740-0B0 HOLLOW RIVET (2.3MMX4.0MMX3.5MM) FOR P401
T8-21APAK-MA1 71-270870-0A9 LABEL
T8-21APAK-MA1 62-227680-0UA
TV RAW SUPPORT CABLE CHASSIS --
00 00 00
T8-21APAK-MA1 62-227680-1UA
TV RAW SUPPORT CABLE FBT -- 01 00
00 R=N
T8-21APAK-MA1 10-GBY228-FPX D-FSR GBY228 1500V 2.5A R=Y D455
T8-21APAK-MA1 11-DD5024-0CX
TR 600V 8_A NPN 35W 1.7MHZ TO-
220F 3DD50
Q402A
T8-21APAK-MA1 11-RFS630-0CXB N-CHANNEL MOSFET IRFS630B Q451
T8-21APAK-MA1 13-00M24C-16P IC-EEPROM M24C16-WBN6 R=N IC202(CP)
T8-21APAK-MA1 13-DA7266-SAS
TCL13-DA7266-SAS= IC TDA7266SA
R=N
IC601
T8-21APAK-MA1 13-STV817-2AS
IC-DEFLECT STV8172A VERTICAL
DEFLECTION
IC301
T8-21APAK-MA1 18-CE0229-JNX
TCL18-CE0229-JNX= RES. C.F. 2.2
OHM 1/2W
J233
T8-21APAK-MA1 25-DFA479-M1XR CAP.ELEC 4.7UF 50V +/-20% C452
T8-21APAK-MA1 25-PJA470-M1X
TCL25-PJA470-M1X= CAP.CELE
47UF/160V/+/-
C419
T8-21APAK-MA1 36-HDR020-XX0 TRANSFORMER HORIZ DRIVE BCT-1621 T402
T8-21APAK-MA1 45-OSC24M-5N6BR CRYSTAL 24.576MHZ 30PPM R=Y X201
T8-21APAK-MA1 46-33079W-02XG PIN BASE *2 TJC3-2A P602
T8-21APAK-MA1 46-33079W-03XG PIN BASE *3 TJC3-3A P603
T8-21APAK-MA1 46-33079W-04XG PIN BASE *4 TJC3-4A P203
T8-21APAK-MA1 46-39402W-04XG BASE P401
T8-21APAK-MA1 63-B30080-BT4G S/T SCREW B 3 X 8 BT FOR Q402
T8-21APAK-MA1 63-B30100-AB4G
SCREW-ST 3MM 10MM JIS B 1122 53 0
0 R=Y
FOR IC301
T8-21APAK-MA1 64-P30080-104G M/C SCREW P 3 X 8 FOR IC601;FOR Q451
T8-21APAK-MA1 67-H27292-2A0 HEAT SINK Y451
T8-21APAK-MA1 67-H30752-GA0 RAW HEATSINK -- GA0 00 R=N Y402
T8-21APAK-MA1 67-H82981-6A0 RAW HEATSINK -- 05 00 R=N Y601

TCL 21M63S-NX56E Specifications

General

Brand	TCL
Model	21M63S-NX56E
Category	TV
Language	English
