T8-21APAK-MA1 67-M40068-2E4 TV RAW SUPPORT -- -- 00 00 00 R=N Y301
T8-21APAK-MA1 71-AV0000-V00 SOFT LABEL PAPER WHITE
T8-21APAK-PW1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D813;D811;D810;D804
T8-21APAK-PW1 10-0FR107-FBX
D-PIN 1.3V 1_A 1000VV 500NS /W
DO-15 FR1
D809
T8-21APAK-PW1 10-0RL255-EBX
D-PIN 1.1V 2_A 800V / /W DO-15
RL255
DB804;DB803;DB802;DB801
T8-21APAK-PW1 10-1N4007-EBX
D-PIN 1.1V 1_A 1000V / /W DO-41
1N4007
D802
T8-21APAK-PW1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D814;D815
T8-21APAK-PW1 10-79C3V9-DBX D-PR /A /
_
V 3.9V BZX79C3V9 ZD803;ZD802
T8-21APAK-PW1 10-79C4V7-DBX D-PR /A /
_
V 4.7V BZX79C4V7 ZD804
T8-21APAK-PW1 10-79C8V2-DBX
D-ZENER BZX55C8V2 8.2V 500MI0W
R=N
ZD805
T8-21APAK-PW1 10-HER108-FBX DIODE HER108 D803
T8-21APAK-PW1 11-2N5551-CBX
TR 160V 0.6_A NPN 0.625W 100MHZ
TO-92 2N
Q802
T8-21APAK-PW1 11-DA8050-CBS
TR 25V 1.5_A NPN 1W 100MHZ TO-92C
3DA805
Q804
T8-21APAK-PW1 11-TC144E-0BX TRANSISTOR DTC144ESA Q808
T8-21APAK-PW1 13-000TL4-31T IC-REGSPECKT TL431ACLP R=N IC802
T8-21APAK-PW1 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% R808
T8-21APAK-PW1 18-CB0122-JNX RES. C.F. 1.2K OHM 1/6W +/-5% R805
T8-21APAK-PW1 18-CB0153-JNX RES. C.F. 15K OHM 1/6W +/-5% R810
T8-21APAK-PW1 18-CB0183-JNX RES. C.F. 18K OHM 1/6W +/-5% R831
T8-21APAK-PW1 18-CB0222-JNX RES. C.F. 2.2K OHM 1/6W +/-5% R820
T8-21APAK-PW1 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% R819
T8-21APAK-PW1 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% R811
T8-21APAK-PW1 18-CB0821-JNX RES. C.F. 820 OHM 1/6W +/-5% R818
T8-21APAK-PW1 18-CD0470-JNX RES. C.F. 47 OHM 1/4W +/-5% R809
T8-21APAK-PW1 18-CE0332-JNX RES. C.F. 3.3K OHM 1/2W +/-5% R841
T8-21APAK-PW1 18-DB0223-FNX
TCL18-DB0223-FNX= RES. M.F. 22K
OHM 1/6W
R803
T8-21APAK-PW1 18-DB0273-FNX RES. M.F. 27K OHM 1/6W +/-1% R832
T8-21APAK-PW1 18-DD0184-FNX RES. M.F. 180K OHM 1/4W +/-1% R829
T8-21APAK-PW1 18-FE0100-JNX
RESISTOR METAL OXIDE FILM 10R0OHM
5% 1/2
R842
T8-21APAK-PW1 18-FE0102-JNX
RESISTOR METAL OXIDE FILM 1K0OHM
5% 1/2W
R804
T8-21APAK-PW1 18-FF0271-JSX RES.M.O.F 1.0W 270 OHM +/-5% R816A
T8-21APAK-PW1 18-FF0680-JSX
RESISTOR 金属氧化膜 68OHM +/-5%
1W RS1FS
R817
T8-21APAK-PW1 18-FG0183-JSX RMOF 18KOHM +/-5% 2W R=Y R814
T8-21APAK-PW1 18-FG0223-JSX RMOF 2W +-5%22KΩ R837
T8-21APAK-PW1 18-FG0569-JSX RMOF 5.6OHM +/-5% 2W R=Y R846
T8-21APAK-PW1 18-KE0105-JNX
RES. GLASS GLAZE 1M OHM 1/2W +/-
5%
R839
T8-21APAK-PW1 18-KE0475-JNX
RES. GLASS GLAZE 4.7M OHM 1/2W
+/-5%
R801
T8-21APAK-PW1 25-BCB101-M1X CAP.ELE 5MM 100UF 16VV 5X11 85 / C842;C844
T8-21APAK-PW1 25-BCB102-M1X CAP.ELE 5MM 1000UF 16V 10X16 85 / C833
T8-21APAK-PW1 25-BDB102-M1X
CAP.ELE 5MM 1000UF 25V 10*20 85
CD110
C827;C829
T8-21APAK-PW1 25-BDB470-M1X CAP.ELE 5MM 47UF 25VV 5X11 85 / C826
T8-21APAK-PW1 25-BDB470-M1X CAP.ELE 5MM 47UF 25VV 5X11 85 / C850;C835;C812;C843A;C847
T8-21APAK-PW1 25-BFB100-M1X CAP. ELEC 10 UF 50V +/-20% C816
