TCL 21M63S-NX56E - Page 70

T8-21APAK-PW1 25-BHB470-M1X
CAP.ELE 5MM 47UF 100V 10*16 85
B41827系
C846
T8-21APAK-PW1 26-AIC221-KBX CAP.CER 220P0F 500VV - C820;C819;C822
T8-21APAK-PW1 26-AKC152-KRX CAP. CER 1500 pF 1KV +/-10% C811A
T8-21APAK-PW1 26-AKC331-KBX CAP.CER 330P0F 1K0V - C817
T8-21APAK-PW1 26-AKC471-KRX CAP.CER 470P0F 1KVV - C805
T8-21APAK-PW1 26-AKC472-MEX CAP. CER 4700 pF 1KV +/-20% C810A
T8-21APAK-PW1 26-EBP102-KBS CAP.CER 1NF 50V - +/-10% B% C838;C814
T8-21APAK-PW1 26-EBP104-ZFS CAP. CER 0.1UF 50V +80%/-20% C813;C839;C851
T8-21APAK-PW1 26-EBP473-ZFS
TCL26-EBP473-ZFS= CAP. CER 47NF
50V +80/
C806
T8-21APAK-PW1 26-EBP561-JCS CAP. CEP 560PF 50V +/-5% C807
T8-21APAK-PW1 35-392170-0IX FERR BEAD BF-I35050R-730 L802
T8-21APAK-PW1 41-WJ0050-B00
TCL41-WJ0050-B00= WIRE BARE
JUMPER 5MM R
J840;J841;J842;J843;J832;J831
;J830;J829
T8-21APAK-PW1 41-WJ0050-B00
TCL41-WJ0050-B00= WIRE BARE
JUMPER 5MM R
J819;J821;J836;J835;J834;J833
T8-21APAK-PW1 41-WJ0050-B00
TCL41-WJ0050-B00= WIRE BARE
JUMPER 5MM R
J823;L804;R845;J839;J844;J828
;J813;J818
T8-21APAK-PW1 41-WJ0055-B00 WIREBAREJUMPER5.5MM J845
T8-21APAK-PW1 41-WJ0075-B00 WIREBAREJUMPER7.5MM J814;J803;J822;R830
T8-21APAK-PW1 41-WJ0085-B00 WIREBAREJUMPER8.5MM J837
T8-21APAK-PW1 41-WJ0095-B00 WIREBAREJUMPER9.5MM J809;J810
T8-21APAK-PW1 41-WJ0100-B00 WIREBAREJUMPER10MM
J802;J801;JP805;JP807;JP808;J
P809;JP810
T8-21APAK-PW1 41-WJ0125-B00 WIREBAREJUMPER12.5MM J820
T8-21APAK-PW1 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR T801;FOR C824
T8-21APAK-PW1 66-343740-0B0 HOLLOW RIVET (2.3MMX4.0MMX3.5MM) FOR C803
T8-21APAK-PW1 10-00RU3C-FPX
D-PIN 2.5V 1.5_A 1000V 0.0001 0W
DO-15 R
D808
T8-21APAK-PW1 10-0RU4YX-FPX D-FSR GRU4YX 100V 4A R=Y D812
T8-21APAK-PW1 10-HS18VC-DBX DIODE 500MW 18HSC
'-' TO C847'+','+' TO C847 '-
'
T8-21APAK-PW1 11-S7N60F-0CX
MOSFET N 600V 7A 48W TO-220F
JCS7N60F
Q801
T8-21APAK-PW1 13-NCP133-7PP OPTICOUP NCP1337P IC801
T8-21APAK-PW1 13-PC123X-9YP
TCL13-PC123X-9YP= PHOTOCOUPLER
PC123X9YF
IC803
T8-21APAK-PW1 18-FH0473-JLX
RESISTOR METAL OXIDE FILM 47K0OHM
5% 3WW
R812
T8-21APAK-PW1 18-KF0825-JH3 RES. H.VOLT.CC 8.2M OHM 1W +/-5% R838
T8-21APAK-PW1 18-MJ0108-JDX RESISTOR CEMENTED 0R1OHM 5% 5WW - R806
T8-21APAK-PW1 22-NTC479-XX0 NTC 4.7D2-14 RT802
T8-21APAK-PW1 22-PTC909-3A5 PTC MZ73BHL-9Ω±20% RT801
T8-21APAK-PW1 25-BDA222-M1S
CAP.ELE 5MM 2200UF 25VV 12.5X25
85 /
C832
T8-21APAK-PW1 25-BJG101-M1X CAP. ELEC 100 UF 160V +/-20% C824
T8-21APAK-PW1 26-AKL103-MFX CAP. CER 10 NF 1KVDC +/-20% C809
T8-21APAK-PW1 26-APL222-MEX CAP. CER 2200PF 400VAC+/-20% E CY803
T8-21APAK-PW1 26-EBP681-JCS CAP. CER 680 PF 50V +/-5% IC801 PIN5 TO PIN4
T8-21APAK-PW1 27-AQT224-MV3
FILM CAPACITOR 220N0F 22.5MMMM
250VACV -
CX802
T8-21APAK-PW1 36-LIF010-XX0 LINE FILTER LCL-2821A LF802
T8-21APAK-PW1 36-TRF326-AX3T
TRANSFORMER SMT +12V +110V 35
BCK-3545E
T801
T8-21APAK-PW1 46-10962W-02XG PIN BASE *2 TJC2-2A CN802
T8-21APAK-PW1 50-04000D-1GS1G FUSE T4AL/250V F801
