TCL 65C809 User Manual

EN
15
English
Using more of your TV
6.
To stop mirroring your iOS or iPadOS device, open
Control Center, tap screen mirroring, then tap stop
mirroring.
Notes:
-
If your WiFi is turned o, press on the remote
control, select
Settings >
Network and Internet
> Wi-Fi
,
and press
OK
to turn it on.
-
To disable the feature, select
Settings > System
> AirPlay and HomeKit Settings > Apple
AirPlay and HomeKit > AirPlay
and press
OK
to turn it o.
-
Apple, AirPlay, HomeKit and Siri are trademarks
of Apple Inc., registered in the U.S. and other
countries and regions.
-
To use AirPlay and HomeKit with this Smart TV
Pro, the latest version of iOS, iPadOS, or macOS
is recommended.
Multi Visual
Allows you to enjoy di󰀨erent programmes with your
family on one TV at the same time.
The multi visual function is enabled by default. To use
the function, make sure your phone is Android OS
and the WiFi on the phone is turned on. Then follow
the steps below to operate.
1.
Press on the remote control, select
Settings >
Network and Internet > Wi-Fi
, and press
OK
to
turn it on.
2.
Press on the remote control,select
Multi Visual
,
then select your desired display mode and press
OK
to connect.
3.
Activate the cast screen function on your phone
and choose the TV’s name you want to connect in
the searching list.
4.
For the rst time, depending on di󰀨erent types of
phones, there are two situations:
- An invitation prompt appears, select
Accept
and
press
OK
to connect.
- Enter a correct PIN code to connect as per the
PIN message on the phone.
5.
To exit the multi visual function, press , then
select
OK
and press
OK
to conrm.
Notes:
-
This feature is not available in any of the cases
below:
• when TV is using Netix or Media Player.
• if the video from phone/DTV is scrambled.
• when the capacity of required video decoding
exceeds 4K 60Hz.
-
When in full screen mode, due to the
compatibility of the third party’s Apps, there might
occur failure to return to the dual views.
-
Multiple phones can be used. When in dual view
mode, use
/
to move the focus to TV view and
then cast another phone to the TV.
-
To check all available history list, press on
the remote control, select
Settings > System
> Multi visual settings > Connection list
and
press
OK
to enter.
Blue Light Filter
It reduces the amount of blue light emitted by
the screen, which can reduce the visual fatigue
associated with screen viewing.
1.
Press on the remote control to display the
dashboard, select
Picture > Advanced settings >
Colour
and press
OK/
to enter.
2.
Select the
Blue Light Filter
option, and press
OK
to
toggle between on or o󰀨.
Notes:
-
After watching TV for half an hour, please move
away from the TV and rest your eyes.
-
When resting, please look far away to adjust the
ciliary muscles of the eye to avoid eye strain.
-
Please form a good habit of doing eye exercises
to protect eyesight and prevent myopia.

TCL 65C809 Specifications

General

Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	65 \
Progressive scan	Yes
Display brightness	1300 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Mini LED
Display diagonal (metric)	165.1 cm
Motion interpolation technology	PPI (Picture Perfomance Index) 4000
Dynamic contrast ratio marketing name	Mega Contrast
Ambient mode	Intelligent Picture
Game features	Auto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
USB recording	No
Processor cores	4
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formats	H.264, H.265, MPEG2
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
RF connector type	F, IEC
RF ports quantity	2
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Music apps	Spotify, TIDAL, YouTube Music
Video apps	Amazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Smart modes	IMAX Enhanced, Sports
Lifestyle apps	Google Apps
Operating system version	ATV 12.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.3
Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Audio decoders	DTS, Dolby Atmos, Dolby Digital, DTS Virtual:X, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power	30 W
Audio output channels	2.0 channels
Equalizer bands quantity	7
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID
Stand type	Center stand
Product color	Black
Heavy metals free	Cd (cadmium)
Panel mounting interface	300 x 300 mm
Cables included	AC
Remote control type	RC833
Cord length	1.5 m
User memory	18.7 GB
Power plug type	Type C
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A73
Package depth	177 mm
Package width	1647 mm
Package height	995 mm
Package weight	27200 g
Pallet width	1650 mm
Pallet height	1135 mm
Pallet length	1080 mm
Quantity per truck	192 pc(s)
Quantity per pallet	6 pc(s)
Number of pallets per truck	32 pc(s)

Weight and Dimensions

Stand width	355 mm
Depth (with stand)	320 mm
Width (with stand)	1444 mm
Height (with stand)	898 mm
Weight (with stand)	20700 g
Depth (without stand)	78 mm
Height (without stand)	840 mm
Weight (without stand)	19600 g
