Page #15 background imageLoading...
Page #15 background image
EN
15
English
Using more of your TV
3. Press
to return to the previous menu.
4. For the rst time, activate the screen mirroring
function on your iPhone, iPad, or Mac and
choose the TV’s name you want to connect in the
searching list.
5. If an AirPlay passcode appears on your TV screen,
enter the passcode on your iOS or iPadOS device.
6. To stop mirroring your iOS or iPadOS device, open
Control Center, tap screen mirroring, then tap stop
mirroring.
Notes:
- If your WiFi is turned o, press on the remote
control, select
Settings >
Network and Internet
> Wi-Fi,
and press
OK
to turn it on.
- To disable the feature, select Settings > System
> AirPlay and HomeKit Settings > AirPlay and
press OK to turn it o.
- Apple, AirPlay and HomeKit are trademarks
of Apple Inc., registered in the U.S. and other
countries.
- This Smart TV Pro is compatible with AirPlay
2 and HomeKit. iOS 12.3 or later or macOS
10.14.5 or later is required.
Multi Visual
Allows you to enjoy di󰀨erent programmes with your
family on one TV at the same time.
The multi visual function is enabled by default. To use
the function, make sure your phone is Android OS
and the WiFi on the phone is turned on. Then follow
the steps below to operate.
1. Press
on the remote control, select Settings >
Network and internet > Wi-Fi, and press OK to
turn it on.
2. Press
on the remote control,then select Multi
Visual > Select your desired display mode and
press OK to enter. Press "Start now" to connect.
3. Activate the cast screen function on your phone
and choose the TV’s name you want to connect in
the searching list.
4. For the rst time, depending on di󰀨erent types of
phones, there are two situations:
- An invitation prompt appears, select Accept and
press OK to connect.
- Enter a correct PIN code to connect as per the
PIN message on the phone.
5. Press the option button to choose the audio
source.
6. To exit the multi visual function, press
, then
select OK and press OK to conrm.
Notes:
- This feature is not available in any of the cases
below:
when TV is using Netix or Media Player.
if the video from phone/DTV is scrambled.
when the capacity of required video decoding
exceeds 4K 60Hz.
- When in full screen mode, due to the
compatibility of the third party’s Apps, there might
occur failure to return to the dual views.
- Multiple phones can be used. When in dual view
mode, use ◄/► to move the focus to TV view
and then cast another phone to the TV.
- To disable the function, press
on the remote
control, select Settings > System > Multi visual
settings > Multi visual,and press OK to turn it
o.
- To check all available history list, press
on
the remote control, select Settings > System
> Multi visual settings > Connection list and
press OK to enter.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 75C835 and is the answer not in the manual?

TCL 75C835 Specifications

General IconGeneral
AC input voltage100 - 240 V
Energy efficiency scaleA to G
Power consumption (standby)0.29 W
Power consumption (typical)- W
Screen shapeFlat
Response time5.7 ms
Display diagonal75 \
Progressive scanYes
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness1500 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate144 Hz
Peak luminance ratio65 %
LED backlighting typeMini LED
Display diagonal (metric)189 cm
Supported graphics resolutions3840 x 2160
Dynamic contrast ratio marketing nameMega Contrast
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Works with Samsung BixbyNo
Music appsAmazon Music, Deezer, Spotify, TIDAL, TuneIn, YouTube Music
Video appsAmazon Prime Video, Apple TV, Netflix, YouTube
Smart modesDolby Vision Bright, Dolby Vision Dark, Dynamic, IMAX Enhanced, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version11
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDTS, Dolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power20 W
Number of speakers2
Equalizer bands quantity7
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesA2DP, HID
Product colorBlack
Panel mounting interface400 x 400 mm
Game featuresAuto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedAVI, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Cables includedAC
Remote control typeRC902V1+RC802NU1
Package typeBox
Package depth255 mm
Package width1832 mm
Package height1160 mm
Package volume541905.6 cm³
Package weight48160 g
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Battery weight15 g
Country of originPoland
Battery technologyAlkaline
Truck type87 cbm
Pallet weight166480 g
Pallet net width1900 mm
Pallet net height1300 mm
Pallet net length800 mm
Quantity per truck126 pc(s)
Quantity per pallet3 pc(s)
Number of layers per pallet1 pc(s)
Number of pallets per truck42 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292518981
Maximum number of stacking cartons2 pc(s)
Repairability index6.7
Digital Living Network Alliance (DLNA) specificationDMP
Weight and Dimensions IconWeight and Dimensions
Stand depth366 mm
Stand width319 mm
Depth (with stand)320 mm
Width (with stand)1670 mm
Weight (with stand)36100 g
Depth (without stand)70 mm
Height (without stand)962 mm
Weight (without stand)33000 g
