TCL 98R754 User Manual

8
In this step, we’ll make sure all systems are a GO!
Connect your power cable to the TV, then plug
it in to the wall outlet.
and descriptions on the next page.
Connect other devices by referencing port label
Power Tip! Always replace depleted batteries with two
same brand-new batteries from the same manufacturer.
Never use damaged batteries.
If your remote gets warm/hot during use, discontinue
use and contact customer support immediately at
support.tcl.com/us.
Insert batteries in the correct polarity as
indicated in the battery compartment.
Power your TV remote by inserting the included
batteries.
remoteGrab yourStep 3
The TV remote should feel right at home in your hand. We designed it to be
incredibly intuitive for watching TV and navigating on-screen menus.
Tip! Follow the on-screen guide
to pair the remote control with
the TV when pressing the
button for the first time.
POWER Turn TV on and o
B
SETTINGS Display the TV settings menu
D
TCL HOME Open TCL home on screen
N
HOME Return to home screen
H
BACK Return to previous screen
I
LIVE GUIDE Open live TV EPGJ
GOOGLE ASSISTANT BUTTON Press to activate the
remote’s Google Assistant microphone. Search content
through your voice by holding down the button.
F
VOLUME Raise and lower volumeG
VIRTUAL KEYBOARD Open virtual keyboard on screen
L
OPTIONS View more options when playing media
A
WATCHLIST Open the Watchlist menu or future function
C
MUTE Press the button to mute the sound.
K
QUICK PANEL Display the quick panel
M
REMOTE MICROPHONE Talk to the remote microphone
after pressing the Google Assistant button
E
E
F
H
G
A
B
C
D
I
K
L N
J
Step 2 Power up
M

TCL 98R754 Specifications

General

Screen shape	Flat
LED backlight	Yes
Response time	- ms
Display diagonal	98 \
Display brightness	- cd/m²
Display technology	QLED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Display number of colors	1.07 billion colors
Display refresh rates supported	48 Hz, 120 Hz
Motion interpolation technology	Natural Motion 480
Game features	Game Studio Pro, Variable Refresh Rate (VRR)
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus)
Package type	Box
Package depth	320.04 mm
Package width	2410.46 mm
Package height	1524 mm
Package weight	81102.32 g
Product color	Black
Panel mounting interface	400 x 850 mm
Batteries	2x AAA
Cables included	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
PC in (D-Sub)	No
HDMI ports quantity	4
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Remote control input capabilities	Voice recognition
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Operating system installed	Google TV
Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus
RMS rated power	30 W
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Weight and Dimensions

Depth (with stand)	424.18 mm
Height (with stand)	1346.2 mm
Weight (with stand)	62595.75 g
Depth (without stand)	101.6 mm
Width (without stand)	2181.86 mm
Height (without stand)	1259.84 mm
Weight (without stand)	59602.04 g
