TCL Alcatel PLUS 10 WIFI Service Manual

L1 Service Manual TCL Communication Ltd.
Rev.
ONETOUCH 8085+LKB001X/A
Level 1 Service Manual
Page
1.1
6/56
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2. General
PLUS 10'' 4G (8085) is a 2 in 1 tablet with Intel Cherry Trail T3 (x5-Z8350) chipset, Quad core 1.44 GHz,
and BT/WLAN, WiFi only etc functions. It originally installed Windows 10 system. It is valuable 10'' 2in1
detachable tablet, slim & lightest in 2in1 segment. LKB001X/LKB001A is a normal keyboard to connect
through 8 hard-pins. It is a full Qwerty keyboard. It can work with EMEA: UMTS 2100/1900/900/850MHz
(B1/2/5/8), LATAM: UMTS B1/2/5/8, US: UMTS B2/4/5(generic PCB).
Detail features
 Plus 10 4G 2 in 1 Tablet
Project Name
PLUS 10'' 4G
Marketing Name
PLUS 10'' 4G Windows
Commercial Name
8085
Chipset & System
Chipset
Intel Cherry Trail T3 (x5-Z8350)
CPU frequence
Quad core 1.44GHz
Operating System
Window 10 Home
Design
Design (dimension) (L x W x H mm)
259.3*156.2*8.35mm
Form factor
Tablet
Side Keys
Volume & Power Key
Removable battery cover
Non-removable
Vibrator
No
Estimated Weight (unit: g) with
battery
465g
Display
Main display vision size (unit:inch)
10.1''
Main display resolution
800*1280
Main display technology
TFT
Main display PPI (unit: pixel/inch)
149.45
Main display color depth
16m (24 bit)
Main display orientation
Portrait & Landscape
Main display touch technology
Capacitive
Touch Panel Type
GFF
LED indicator
No
Ports
SIM Card Number
No
USB
Micro-USB

TCL Alcatel PLUS 10 WIFI Specifications

General

Brand	TCL
Model	Alcatel PLUS 10 WIFI
Category	Tablet
Language	English
