TCL Alcatel PLUS 10 WIFI Service Manual

L1 Service Manual TCL Communication Ltd.
Rev.
ONETOUCH 8085+LKB001X/A
Level 1 Service Manual
Page
1.1
8/56
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
 Plus 10 LTE Keyboard
Project Name
PLUS 10'' LTE KB
Marketing Name
PLUS 10 keyboard
Commercial Name
LKB001X for EMEA
LKB001A for LATAM
General
Chipset
3G/4G chipset: Qualcomm MDM9207,
Cortex A7 1.2GHz, single core
WiFi chipset: RTL8189ES-CG
Form factor
LTE Keyboard
Color
Volcano Black, Silver, White
Dimensions XxYxZ (mm)
263.32*166.88*3.33~7.45mm
Weight
340g
Angles support
65° in notebook mode; 65° in display
mode
Water proof
Global version: follow ALCATEL
standard
Technology/Bands
FDD LTE
EMEA: FDD LTE B1/3/7/8/20/28A
(B28A compatible design, default no
for EU in 2016)
LATAM: FDD LTE B2/3/4/7/13/17/28.
US: FDD LTE B2/4/5/7/12/17.
UMTS/HSPA/HSPA+
EMEA: UMTS
2100/1900/900/850MHz(B1/2/5/8)
LATAM: UMTS B1/2/5/8.
US: UMTS B2/4/5(generic PCB)
Button
Power
N/A
3G/4G
Press to turn 3G&4G on/off.
Reset
1, Long press 3G/4G on/off for 6 secs
to reboot LTE PCBA functionality in
case it's crashed.
2, In case the normal keyboard
functionality is "dead", just take apart
the tablet from keyboard dock pin
connection and put it back for
connection to "restart" the
functionality.
External Interface
Micro USB
Micro USB x1 (for charging only)
When plug in 5V/3A charger to
keyboard micro USB jack, will supply

TCL Alcatel PLUS 10 WIFI Specifications

General

Brand	TCL
Model	Alcatel PLUS 10 WIFI
Category	Tablet
Language	English
