1 Level 2 repair process
 For tablet (8085)
Reassembly
Record in BIG
End
OK
Retest
OK
OK
Start
Visual Inspection
Warranty Check
Pretest & Failure confirm
System firmware install
Disassembly
L2 Repair
Retest
IMT tool test
PCBA Replace
NG
NG
NG
Restore User Information
Back up user data
Delete the IMT tool in tablet
Note: If the device can’t power on,
please disassembly the device and
proceed with L2 repair.
