TCL Alcatel PLUS 10 WIFI User Manual

L2 Repair Document TCL Communication Ltd.
Rev.
ONETOUCH 8085+LKB001X/A
Level 2 Repair Document
Page
1.0
54/71
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
5.5 Disassembly process evaluation
We list the 8085 and LKB001 parts disassembly time, technique levels and disassembly methods as below,
for technique levels, Class 1 signifies easy to disassembly, Class 2 signifies normal to disassembly and
Class 3 signifies hard to disassembly.
Spare part
Time
for
disasse
mbly
Jigs for
disassembly
Difficulty
Class
Remark
8085
Furnished
battery cover
6s
Plastic flake
Class 2
Screws
26s
Screwdriver
Class 1
Main PCBA
15s
Tweezers
Plastic Flake
Class 2
Main camera
2s
Screwdriver
Plastic Flake
Class 1
Front Camera
2s
Plastic Flake
Class 1
Speaker
10s
Tweezers+
soldering iron
Class 2
FPCs
4s
Tweezers
Class 1
LCD
2s
/
Class 1
Back camera
lens
4s
Pry bar
Class 1
battery
3s
Pry bar
Tweezers
Class 1
LKB001
Furnished
back cover
10s
Plastic flake
Class 2
Screws
30s
Screwdriver
Class 1
PCBA
5s
Plastic flake
Class 1
Middle
support
10s
Plastic flake
Class 2
Touch Pad
10
Plastic flake
Class 2
Battery
5s
Plastic flake
Class 1
6 Disassembly Complete
 Explored view
Please get the explore view from TS website: https://css.tclmobile.cn/.
 Please get the latest SPL in Forlog system.
