L2 Repair Document TCL Communication Ltd.
Rev.
ONETOUCH 8085+LKB001X/A
Level 2 Repair Document
Page
1.0
45/71
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Step 11: Disassembly complete.
(2) The steps of disassembly LKB001 are as below.
Step1: Remove the FRONTCASINGRUBBER and the 2 screws with tweezers and screw driver.
