 Display failure
Check whether the connection
b e t w e e n LCD a n d LCD
connector is good
N
N
Check whether LCD connector is
normal
Y
Check whether LCD is
nor mal （ in ter cha nge
method）
N
Reassemble LCD
Reweld or replace LCD
connector
Change LCD
Y
Y
Replace PCBA
Display failure
Y
Y
