Colour Television Chassis: M123A
61
Menu 9(Remote key:9)
Item Remark
V01 Volume 1
V25 Volume 25
V50 Volume 50
V100 Volume 100
VOLMAX Max volume under hotel mode
CURTCEN Center of the curtain
VOLX Output gain of PIN28 of TMPA8823 or MSP34x5
PWTM When use PWM to mute and no sound when changing channel, this item should be
minimum as posible
Menu 10(Remote key: 0)
Item Remark
MDOE4 Bit 0 TV Color system AUTO 1 yes 0 no
Bit 1 TV Color system NTSC358 1 yes 0 no
Bit 2 TV Color system PALM 1 yes 0 no
Bit 3 TV Color system PALN 1 yes 0 no
Bit 4 AV Color system AUTO 1 yes 0 no
Bit 5 AV Color system NTSC358 1 yes 0 no
Bit 6 AV Color system PALM 1 yes 0 no
Bit 7 AV Color system PALN 1 1 yes 0 no
MDOE5 Bit 0 English: 1 yes 0 no
Bit 1 French: 1 yes 0 no
Bit 2 Portuguese: 1 yes 0 no
Bit 3 Spanish : 1 yes 0 no
Bit 4 AV Color system PAL443 1 1 yes 0 no
Bit 5 AV Color system NTSC443 1 1 yes 0 no
Bit 6 AV AUTO 1:AUTO1(PAL443 NTSC358 NTSC443)
0:AUTO2(NTSC358 PALM PALN)
Bit 7 \
MDOE6 Bit 0 1:auto search function of the menu key on the front panel
Bit 1 1: curtain when turn on the set
Bit 2 1: curtain when turn off the set
Bit3~ 7V-mute timing when changing channel(01H = 8ms) max :248ms
MDOE7 Bit 0 When sound mode change
Bit 1 11:change to the corresponding mode and ODS display automatically
01: change to the corresponding mode and ODS doesn't display
00,10: change to MONO ODS doesn't display
Bit 2 10 detect BTSC and Korea stereo automatically
Bit 3 01 force BTSC 11 force Korea stereo
Bit 4 FINE, 1:yes 0 no
Bit 5 50Hz block 1:yes 0 no
Bit 6 1: contrast change when power on
Bit 7 \
9. Alignment Procedures
