Colour Television Chassis: M123A
64
Menu 19 (Remote key: PICTURE)
Item Remark
M-COL Mild colour
M-BRI Mild brightess
M-CON Mild contrast
M-SHP Mild sharpness
Menu 20: no shortcut key
Item Remark
SEG_POINT1 Highest frequency of VHFL
SEG_POINT2 Highest frequency of VHFH
DATA_VL VHFL bandswitch BB
DATA_VH VHFH bandswitch BB
DATA_UF UHF bandswitch BB
SPE_POS1 The channel number treated specially
SPE_DATA1 Bandswitch in which the special channel BB
SENSI_ON
SENSI_OFF
Menu 21: no shortcut key
Item Remark
THEATER-BAS Theater bass
THEATER-TRE Theater treble
CONCERT-BAS Concert bass
CONCERT-TRE Concert treble
BROCAST-BAS Brocast bass
BROCAST-TRE Brocast treble
Menu 22: no shortcut key
Item Remark
VOL_MAI Volume Loudspeaker
GATE Carrier-Mute
VOL-OUT AV output gain
AV GAIN AV input Gain
Note:
Provided the production line is equipped with the self-adjusting equipment, The adjusted
item should be based on the result by such equipment.
There's difference between PAL geometric/OSD adjustment and NTSC geometric/OSD
adjustment. PAL adjustment must be done before NTSC adjustment.
9. Alignment Procedures
