Factory Alignment Specification of normal SIACP
Page 4 of 12
FeatureSpecification
These chassises are designed for South America LCD TV. The main chip is from Mediatec
(MT5310 series) and supports below inputs and outputs:
class item Status MT10B-LA MT10L-LA
ATV
( PAL- M/N, NTSC-M)
¥ Cable&Antenna Cable&Antenna
DTV
(SBTVD-T)
¥ Antenna Antenna
HDMI
(480i/p, 576i/p, 720p up to
1080i/p, compliant v1.2. with
HDCP)
3 P300
P301
P302
P301
P302
P303
VGA
1 P406 P406
VGA/DVI audio
1 P400 P400
CMP
(YPrPb can support from 480i
up to 1080p,audio)
1P1
P455 (Audio)
P404
Side AV or back AV
(CVBS,audio)
2 P304
P404
P423
P421
USB player
(picture,video,audio)
2 P303
P401
P401
P427
Headphone output
¥ P800 P800
SPDIF output
Optical P405 P405
AV out
1 P498 P407
P424
P425
Input
&
Output
function
Others
VGA connector of MT5310B definition:
VGA: Pin4:RXD VGA Pin11:TXD

