TCL L32F3300 User Manual

H4-32F339Z-AGSA0AA 75-939120-CC2 RAW POLYFOAM TOP 32F3300-CN -- 00 00 R=Y
H4-32F339Z-AGSA0AA 74-110075-50HEM DEC BAG -- R=N
H4-32F339Z-AGSA0AA 74-022032-5WEEM DEC BAG -- R=Y
H4-32F339Z-AGSA0AA 74-008010-12CR RAW BAG PE 80MMX100MM (AUTO LOCK) -- 00 装螺钉
H4-32F339Z-AGSA0AA 74-007026-60CR POLYBAG (70MMX260MMX0.06MM) 装电源
线
H4-32F339Z-AGSA0AA 63-B4010T-BF4G SCREW-ST 4MM 10MM ISO R=Y 固定VES
A
H4-32F339Z-AGSA0AA 46-LL020L-12X02G WIRE DC WIRE 200MM 12 PH PH 2.0MM UL2651
H4-32F339Z-AGSA0AA 46-FM060L-07P01G IR WIRE 600MM 7 A200
H4-32F339Z-AGSA0AA 46-FM060L-04P01G WIRE CABLE 600MM 4 A2008 A1250/1255 2.0
H4-32F339Z-AGSA0AA 46-FL020L-28W01G WIRE DRIVER LINE 200MM 12PIN PHD(LOCK) P
H4-32F339Z-AGSA0AA 46-CN040L-04A03G WIRE SPEAKER WIRE 400MM 4 TJC3 187 2
H4-32F339Z-AGSA0AA 46-60HA50-AAB01G WIRE LVDS 500MM 40-30PIN PHD PHD 2.0-1.0
H4-32F339Z-AGSA0AA 41-UK0150-0KK02 WIRE 2.6MM 0D2.6/7.8(9/0.10BC+S25/0.10BC FOR P30
4
H4-32F339Z-AGSA0AA 41-UK0150-0KK01 WIRE 2.6MM 0D2.6/7.8(9/0.10BC+S25/0.10BC FOR P1
H4-32F339Z-AGSA0AA 41-40398H-02X WIRE 3.2MM UL AWG/1C(7/0.12TS) 150MM FOR P45
5
H4-32F339Z-AGSA0AA 08-RL261C1-DR200B
A
ASS'Y - LED DRIVER(DRL2611)
08-RL261C1-DR200BA 67-H90371-2A0 RAW HEATSINK HEATSINK 00 00 R=Y H1
08-RL261C1-DR200BA 64-Z30080-114G Screws FOR Q60
1
08-RL261C1-DR200BA 46-40336W-14XG CONN PH 14 2.0MM FEMALE R P601
08-RL261C1-DR200BA 46-40336W-05XG CONN PH 5 2.0MM FEMALE R P602
08-RL261C1-DR200BA 40-RL2610-DRC1XG PCB DR 214X185MM 6PC SINGLESIDED 1.6MM 1 PCB
08-RL261C1-DR200BA 36-WID101-XX5 OTHER-CI 100UH 0.22OHM 500V 3.5A LC-101- L601
08-RL261C1-DR200BA 27-MGK105-K0X FILM CAPACITOR 0.000 001F 10% 250V 0.5 C C611
08-RL261C1-DR200BA 25-NEF331-M1X CAP.ELE 105DEGREE C 0.00033F 20% 35V 103 C601
08-RL261C1-DR200BA 25-GJF220-M1X CAP.ELE 5MM 22UF 160V 10*20 105 B43044S1 C613
08-RL261C1-DR200BA 25-GJF220-M1X CAP.ELE 5MM 22UF 160V 10*20 105 B43044S1 C612
08-RL261C1-DR200BA 11-9A20DA-0CX MOSFET N 200V 9A 1.5~3.5V 0.4OHM 30W TK9 Q601
08-RL261C1-DR200BA 08-RL261C1-DR2STB
A
ASS'Y - LED DRIVER(DRL2611)SMT PARTS
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R633
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R631
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R649
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R630
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R648
08-RL261C1-DR2STBA 19-CD0109-FTX SMD.RES 1206 1OHM 1/4W +/-1% R629
08-RL261C1-DR2STBA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R620
08-RL261C1-DR2STBA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R617
08-RL261C1-DR2STBA 19-CD0100-JTX RES. MELF 10 OHM 1/4W +/-5% R604
08-RL261C1-DR2STBA 19-BC0753-FTX SMD.RES 0805,1/8W,±1%,75KΩ R624
08-RL261C1-DR2STBA 19-BC0683-FTX SMD.RES 0805,1/8W,±1%,68KΩ R609
08-RL261C1-DR2STBA 19-BC0682-FTX SMD.RES 0805,1/8W,±1%,6.8KΩ R638
08-RL261C1-DR2STBA 19-BC0513-JTX SMD.RES 0805,1/8W,±5%,51KΩ R602
08-RL261C1-DR2STBA 19-BC0472-JTX SMD. RES 4.7K OHM 1/8W +/-5% R606
08-RL261C1-DR2STBA 19-BC0471-JTX SMD.RES 470 OHM 1/8W +/-5% R622
08-RL261C1-DR2STBA 19-BC0471-JTX SMD.RES 470 OHM 1/8W +/-5% R627
08-RL261C1-DR2STBA 19-BC0470-JTX SMD.RES 0805,1/8W,±5%,47Ω R614
08-RL261C1-DR2STBA 28-BD0225-ZFX CAP.CER,SMD 2U2F 25V DCV 0805 - C617
08-RL261C1-DR2STBA 28-BC0106-KBX CAP.CER,SMD 10UF 16V 0805 08053R106K160B C606
08-RL261C1-DR2STBA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C602
08-RL261C1-DR2STBA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C603
08-RL261C1-DR2STBA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C605
08-RL261C1-DR2STBA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C618
08-RL261C1-DR2STBA 28-BB0331-JCX SMD. CAP 330 PF 50V C 0805 C608
08-RL261C1-DR2STBA 28-BB0331-JCX SMD. CAP 330 PF 50V C 0805 C615
08-RL261C1-DR2STBA 28-BB0104-KBX CAP.CER,SMD 100N0F 50V DCV 0805 - C607
