TCL L32F3300 User Manual

H4-32F339Z-AGSA0AA 08-PE061C3-PW200D
A
ASS'Y - POWER BD (PE061C3)
08-PE061C3-PW200DA 08-PE061C3-PW300D
A
ASS'Y - POWER BD (PE061C3)
08-PE061C3-PW300DA 46-40338W-12XG CONN PHD 12 2.0MM FEMALE R P2
08-PE061C3-PW300DA 46-39219W-03XG PIN BASE VH-3AW CN1
08-PE061C3-PW300DA 40-E061C3-PWH1XG PCB PSU 200 X 170 MM 2PC SINGLESIDED 1.6 PCB
08-PE061C3-PW300DA 36-WID848-XX0 OTHER-CI 0.00000084H 7% 100000HZ 0.02OHM L102
08-PE061C3-PW300DA 36-TRF393-LX0 TRANSFORMER FLYBACK TRANSFORMER 0.00032H TS1
08-PE061C3-PW300DA 36-TRF393-BX0 TRANSFORMER FLYBACK 0.000285H 24V 12V ER TS1
08-PE061C3-PW300DA 36-LIF212-TX1 COILS AND INDUCTORS 200UH 1500V FILTER 1 LF1
08-PE061C3-PW300DA 36-LIF212-JX0 COILS AND INDUCTORS 200UH 1500V FILTER 1 LF1
08-PE061C3-PW300DA 36-LIF206-JX0 COILS AND INDUCTORS 18MH 1500V FILTER 3A LF2
08-PE061C3-PW300DA 36-LIF206-BX0 COILS AND INDUCTORS 0.012H 1500V FILTER LF2
08-PE061C3-PW300DA 27-AQK474-KV6T 0.47UF 10% AC275V </=0.1% MPX-474K27L15L CX1
08-PE061C3-PW300DA 46-40338W-28XG CONN PHD 28 2.0MM FEMALE R P1
08-PE061C3-PW300DA 50-03150D-6GS3G FUSE 3.15A 250V F1
08-PE061C3-PW300DA 57-893390-0UG RAW HOLDER SPACE -- 00 00 R=Y A6
08-PE061C3-PW300DA 64-Z30080-114G Screws FOR QW1
08-PE061C3-PW300DA 64-Z30080-114G Screws FOR DS1
08-PE061C3-PW300DA 66-20516X-1B0 RAW HOLDER FUSE -- 01 00 R=Y FOR F1
08-PE061C3-PW300DA 67-H88056-GA0 RAW HEATSINK POWER 00 00 R=Y H1
08-PE061C3-PW300DA 67-H88056-GA0 RAW HEATSINK POWER 00 00 R=Y H2
08-PE061C3-PW300DA 67-M60442-1E0 TV RAW SPRING GND-15 00 01 R=Y A4
08-PE061C3-PW300DA 67-M60442-1E0 TV RAW SPRING GND-15 00 01 R=Y A5
08-PE061C3-PW300DA 67-M60442-1E0 TV RAW SPRING GND-15 00 01 R=Y A1
08-PE061C3-PW300DA 08-PE061C3-PW3AID
A
ASS'Y - POWER BD (PE061C3)AI PARTS
08-PE061C3-PW3AIDA 41-WJ0100-B00 WIREBAREJUMPER10MM J6
08-PE061C3-PW3AIDA 41-WJ0100-B00 WIREBAREJUMPER10MM J7
08-PE061C3-PW3AIDA 41-WJ0060-B00 WIRE-BARE J13
08-PE061C3-PW3AIDA 35-LB1009-0IX BEAD CORE INDUCTOR LB3.5X1X9 L101
08-PE061C3-PW3AIDA 27-MHB222-J0X FILM CAPACITOR 0.0000000022F 5% 400V 0.0 C101
08-PE061C3-PW3AIDA 26-AKC221-KRX CAP.CER 220P0F 1K0V - C110
08-PE061C3-PW3AIDA 26-AIC102-KBX CAP.CER 1N0F 500VV - C114
08-PE061C3-PW3AIDA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C106
08-PE061C3-PW3AIDA 41-WJ0105-B00 WIREBAREJUMPER10.5MM J3
08-PE061C3-PW3AIDA 41-WJ0105-B00 WIREBAREJUMPER10.5MM J4
08-PE061C3-PW3AIDA 41-WJ0110-B00 WIREBAREJUMPER11MM J1
08-PE061C3-PW3AIDA 41-WJ0125-B00 WIREBAREJUMPER12.5MM J11
08-PE061C3-PW3AIDA 41-WJ0190-B00 WIREBAREJUMPER19MM J5
08-PE061C3-PW3AIDA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR TS1
08-PE061C3-PW3AIDA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR CX1
08-PE061C3-PW3AIDA 66-343740-0B0 HOLLOW RIVET (2.3MMX4.0MMX3.5MM) FOR CN1
08-PE061C3-PW3AIDA 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) DS2
08-PE061C3-PW3AIDA 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D105
08-PE061C3-PW3AIDA 10-0FR107-FBX D-PIN 1.3V 1_A 1000VV 500NS /W DO-15 FR1 D113
08-PE061C3-PW3AIDA 10-0FR107-FBX D-PIN 1.3V 1_A 1000VV 500NS /W DO-15 FR1 D106
08-PE061C3-PW3AIDA 10-0RL206-EBX D-VC 2A 800V 1.1V 5.0UA 120A /SEC /W RL2 BD1
08-PE061C3-PW3AIDA 10-0RL206-EBX D-VC 2A 800V 1.1V 5.0UA 120A /SEC /W RL2 BD2
08-PE061C3-PW3AIDA 10-0RL206-EBX D-VC 2A 800V 1.1V 5.0UA 120A /SEC /W RL2 BD3
08-PE061C3-PW3AIDA 10-0RL206-EBX D-VC 2A 800V 1.1V 5.0UA 120A /SEC /W RL2 BD4
08-PE061C3-PW3AIDA 25-MFB479-K1X CAP.ELE 5MM 4.7UF 50VV 5*11 105 \ C120
08-PE061C3-PW3AIDA 25-GCB471-M1X CAP.ELE 5MM 470UF 16V 8X12 105 / C115
08-PE061C3-PW3AIDA 25-GCB221-M1X CAP.ELE 5MM 220UF 16VV 6.3*11 105 \ C125
08-PE061C3-PW3AIDA 10-1N4007-EBX DIODE 1N4007 D101
08-PE061C3-PW3AIDA 10-0RL255-EBX D-PIN 1.1V 2_A 800V / /W DO-15 RL255 BD1

TCL L32F3300 Specifications

General

Brand	TCL
Model	L32F3300
Category	LCD TV
Language	English
