12
5.Disassemble the lower hinge assembly, and then install the leveling foot and screw nut (as
shown in the right figure).
6.Replace the lower hinge assembly with the leveling angle, and install the lower door.
7.Install the middle hinge at the left mounting position, and install the previously removed screw
cover to the right screw hole.
8.Install the door, connect the terminals, install the upper hinge, the upper hinge cover and the
previously removed screw cover. Reverse door complete. (the upper hinge and hinge cover are
installed on the left as shown in the figure, and the screw cover is in the right position)
9.After the operation is completed, please stand still for a period of time and turn on the power.
Operation notes
