Step 4 Get to know your TV
F
HDMI ARC PORT Connect HDMI ARC (audio
return channel) capable audio devices like
sound bars or AV receivers.
H
G
D
E
/ANTENNA CABLE IN
Connect an outdoor VHF/
UHF antenna or Cable TV feed.
TV SIDE
D
F
G/F
H
J
K
L
I
E
TV FRONT
A
IR RECEIVER
Receives signal from
the TV remote.
STATUS LIGHT
Glows when the
TV is in standby.
A
POWER PORT Connect your TV
C
to the power source with the
included power cable.
POWER and OPTIONS BUTTON
B
Press once to open the menu.
Press and hold to turn o the TV.
RESET
CABLE/ANT
AUDIO OUT
AV IN
ARC
B
TV BACK
C
home Internet router or switch.
ETHERNET Connect an Ethernet cable to your
RESET BUTTON
Press once to restart your TV.
Press and hold for factory reset, and careful,
you will lose all your settings!
PORT
Highest quality audio/video
connection. Connect cable box, Blu-ray player,
gaming console, or other devices to your TV
using HDMI cables.
HDMI
I
OPTICAL (DIGITAL AUDIO OUT) Connect an
optical cable to an external digital audio system.
The AV Input can be used to connect older devices
that use analog audio/video outputs. Compatible
adapter (not included) connects to the RCA cable
(video - yellow and audio - white and red) that you
normally use to connect to that device.
AV IN adapter AV Input (analog audio/video).
L
J
HEADPHONE OUT Connect headphones or
other external speakers.
K
USB PORT Connect a USB device to access
photos, music and movies.
