Optional - To mount on a wall
(wall mount not included)
Preparation must be done before mounting your TV on a wall.
To mount on a wall
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
55” Models
Purchase a VESA 200x200, 4 M6x25mm screws
To mount your TV to the wall, purchase a VESA wall mount
If you are mounting your TV to the wall, don’t attach the stands.
65” Models Purchase a VESA 300x300, 4 M6x12mm screws
1 2
3 4
For 55” models, screw o the 4
screws on the back of the TV.
For 65” models, screw o the 2
screws on the top of the TV back.
For 55” models, skip to step 3.
For 65” models, screw the 2 VESA
adapter screws into the 2 screw
holes on the top of the TV back.
Screw the VESA bracket tightly
onto the back cover with 4
VESA screws.
6
Follow the instructions that come
with the wall mount to hang the
TV on the wall.
VESA screws:
55”: M6x25mm
65”: M6x12mm
