TCL Air Conditioner Service Manual
2. PRODUCT DIMENSIONS
Indoor Unit:
Outdoor Unit:
Model A B C D E F G H I J K
TAC-07CHSA/VB
728 205 285 600 500 232 439 276 375 52 55
TAC-09CHSA/VB
728 205 285 600 500 232 439 276 375 52 55
TAC-12CHSA/VB
728 205 285 700 552 256 439 302 277.8 48 55
TAC-24CHSA/VB
972 225 310 820 605 300 518 357 329 55 63
