TCL Air Conditioner Service Manual
6
Model No. TAC-12CSC/K TAC-12CHSC/K TAC-18CSC/K TAC-18CHSC/K
Type Cooling Only Heating Pump Cooling Only Heating Pump
Control type Remote Remote Remote Remote
Rated cooling capacity Btu/h 12,000 12,000 18,000 18,000
Rated heating capacity Btu/h N/A 12,800 N/A 1,9000
EER for cooling Btu/h.w 10.9 10.9 9.5 9.5
COP for heating W/W N/A 3.2 N/A 2.8
Moisture removal Liters/h 1.0 1.0 1.5 1.5
High dB(A) 38 38 43 43
Med. dB(A) 36 36 40 40
Indoor noise level at
cooling
Low dB(A) 32 32 36 36
Outdoor noise level dB(A) 52 52 58 58
Electrical Data
Power supply 220-240V~/50Hz
Voltage Range V 198~264 198~264 198~264 198~264
Cooling A 5.5 5.5 8.7 8.7
Rated current
Heating A N/A 5.5 N/A 8.7
Cooling W 1170 1170 1900 1900
Rated input
Heating W N/A 1170 N/A 1900
Refrigerating System
Refrigerant/Charge Gram R407C/1450g R407C/1450g R407C/1800g R407C/1800g
Type Rotary Rotary Rotary Rotary
Model ------------------ ----------------- ------------------ ------------------
LRA A ------ ------- ------ ------
Compressor
MFG ----------------- ----------------- ---------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 550 550 730 730
Indoor fan type Cross flow Cross flow Cross flow Cross flow
Cooling rpm 1230/1150/1000 1230/1150/1000 1060/970/880
1060/970/880
Heating rpm N/A 1230/1150/1000 N/A
1060/970/880
Dry rpm 1000 1000 880 880
Indoor fan speed
H/M/L
Sleep rpm 1000 1000 880 880
Indoor fan motor output W 12 12 25 25
Outdoor air circulation m
3
/h --- --- --- ---
Outdoor fan type Propeller fan Propeller fan Propeller fan Propeller fan
Outdoor fan speed rpm 860 860 850 850
Outdoor fan motor output W 55 55 85 85
Connections
Refrigerant coupling Flare type
Gas Inches 3/4 3/4 3/4 3/4
Connecting Pipe
Liquid Inches 7/16 7/16 7/16 7/16
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
16~28 16~28 30~40 30~40
Indoor mm 770×250×179 770×250×179 1036×313×204 1036×313×204Net dimensions
(W x H x D)
Outdoor mm 760×255×540 760×255×540 890×307×660 890×307×660
Indoor kg 8.0 8.0 13 13
Net weight
Outdoor kg 37 37 48 48
Indoor mm 863×325×270 863×325×270 1103×395×280 1103×395×280Packing dimensions
(W x H x D)
Outdoor mm 863×376×605 863×376×605 990×405×705 990×405×705
Indoor kg 10 10 10 10
Gross weight
Outdoor kg 35 36 35 36
Loading Capacity 40’/40’HC 112/236/248 112/236/248 66/142/162 66/142/162
