Outdoor Unit- TAC-07CSA/M, TAC-09CSA/M,TAC-12CSA/M
No. Part No. Part Name Q’ty Remark
1 Grille 1
Optional
2 Top Cover 1
3 Condenser 1
4 Outdoor Motor Supporter 1
5 Outdoor Motor 1
6 Propeller Fan 1
7 Left Grille Supporter 1
8 Left Grille 1
9 Front Plate 1
10 Fan Guard 1
11 Capillary Assembly 1
12 Compressor and its Accessories 1
13 Discharge Pipe 1
14 Suction Pipe 1
15 Base 1
16 Two-way Valve 1
17 Valve Supporter 1
18 Three-way Valve 1
19 Right Plate 1
20 Electrical Box Cover 1
21 Capacitor Strip 1
22 Cable Clamp(φ8) 1
23 Terminal 1
24 Compressor Capacitor 1
25 Fan Motor Capacitor 1
26 Electrical Parts Box 1
27 Base Carton 1
28 Cabinet Carton 1
29 Base Foaming 1
30 Cover Forming 1
Not shown in the Explosion
view.
