TCL Air Conditioner Service Manual
9
A010283
Outdoor unit
9K, 12K
A010313
1
ODU PCB Mainly
relay
2 Fuse
3
L, N & 1
(communication)
wiring
4 4-way valve
5 Heater
6
DC fan motor
connector
7
Electronic expansion
valve
8
Discharge sensor
connector
9
OAT/OPT sensor
connector
10 LED5
10
9
8
7 6
5
4
3
2
1
