TCL TAC-24CS User Manual

Cooling capacity - 1/5 Case-11
Factor
Cooling capacity downs by bad air flows.
Spacing for the air flows in split type air conditioners.
Troubles &
Causes
Defect Details
Guidelines
■ Ensure the distance needed for air flows.
■ Bad air flows lead cooling capacity's drop.
(The product may not run normally as the accumulated heat make compressor stop by protecting
device's work like PTC)
1. The space for air intake is too narrow. 2. The space for air discharge is too narrow.
10cm
50cm
Wall
Wall Wall
Wall
TCL Air Conditioner Service Manual
30

TCL TAC-24CS Specifications

General

Capacity	2 Ton
Power Supply	220-240V, 50Hz
Refrigerant	R410A
Weight (Outdoor Unit)	45 kg
Type	Split
Operating Temperature (Cooling)	18°C to 43°C
Noise Level (Indoor Unit)	42 dB(A)
