3) Disassembly of refrigerator air duct cover plate:
1. Remove one screw of the air duct cover plate with a screwdriver, and then take out the air duct cover plate carefully;
2. Pull out the connector of air duct cover plate by hand;
3. Remove two screws of the air swing motor with a cross screwdriver and replace the motor;
4. Unplug the connector of air duct foam assembly by hand and remove the duct foam by hand.
5. Tear off the foam masking taper with hands, separate the upper and lower parts of the air duct foam assemblies and
take out the damper and replace it.
6. During installation, please see to it that the buckle be embedded as shown in the figure to prevent air leakage.
