Teac A-2300SD - Exploded Views and Parts List

CONTENTS OF PARTS LIST
PARTS ORDERING INFORMATION
Parts Ordering Information.22
Assembling Hardware Coding List.23
Included Accessories .31
11. Exploded Views and Parts List
11-1. Main Chassis Group .24
11-2. Motor Chassis Group . . 2 6
11-3. Front Panel...28
11- 4. Rear Panel .30
12. PC Board Section
12- 1. Amplifier A-circuit.32,38
12-2. Control Relay .32,38
12-3. Amplifier B-circuit.33,38
12-4. Rear Panel PC Board .33,39
12-5. Dolby "B" Processor..34,40
12-6. Bias Oscillator .35,42
12-7. Muting PC Board.36,42
12-8. Control PC Board ..36,43
12-9. SW Mounting PC Board.37,43
Spare parts are available through your nearest TEAC Authorized
Service Center or directly from the TEAC office, the address of which
is written on the back cover. When ordering parts, always include the
following information:
1. MODEL 4. DESCRIPTION
2. REF. NO. 5. UNIT SERIAL NO.
3. PARTS NO. 6. MANUAL CODE NO.
NOTICE REGARDING PARTS ORDERS
1. Do not order by only REF. NO.
2. In some instances, individual minor parts are not available.
In such a case, the entire assembly including the part requested
will be sent to you.
PARTS IDENTIFICATION CODING
Parts are identical between the different models with the exceptions
as coded by the designations explained below.
TCA TEAC Corporation of America, U.S.A.
version only
CAN lor CANADA) Canada version only
EX All export versions (except TCA, CAN or
Japan).
)
)
