SERVICE MANUAL
2
CONTENTS
SPECIFICATION ...................................................................................................................................................
MEASUREMENTS AND ADJUSTMENTS .........................................................................................................
PIN FUNCTION ....................................................................................................................................................
WIRING DIAGRAM ..............................................................................................................................................
BLOCK DIAGRAM ................................................................................................................................................
SCHEMATIC DIAGRAM ....................................................................................................................................
PRINTED CIRCUIT BOARDS .............................................................................................................................
EXPLODED VIEW...............................................................................................................................................
ELECTRICAL PARTS LIST .................................................................................................................................
Specifications
AMP Section
Power output : 35 W+35W
(8 , 1kHz, 0.5%)
Total harmonic distirtion : 35 W+35W
(40W, 1kHz, 8 )
S/N Ratio(inout Short) :
Phono : 60dB(IHF-A)
CD, Tuner, Aux, Tape : 90dB(IHF-A)
Input Sensitivity/Im pedance :
Phono(MM) : 2.5m V/47k
CD, Tuner, Aux, Tape : 200m V/47k
Channel Separation : 60dB
(Input Short) : (1kHz, 1W, B.P.F)
Residual noise : 60m V
Frequency response : 20Hz to 65kHz
Tone control :
Bass : 10dB(100Hz)
Treble : 10dB(100Hz)
Required speaker im pedance : 8 to 16
General
Power Requirements : 230V AC, 50Hz[EUR]
120V AC, 60Hz[T/C]
Power Consumption : 85W
Dimensions(W x H x D) : 215 x 110 x 307
Weight(net) : 4Kg
FM Section
Tuning Rane : 87.50M Hz~ 108.00MHz
(50kHz steps)[EUR]
76.0MHz~ 90.0MHz
(100kHz steps)[DM]
87.50MHz~ 108.00MHz
(100kHz stepe)[T/C]
Usable Sensitivity(IHF) : M ono:15dBf
50dB Quieting Sensitivity :
Mono : 30dBf
Stereo : 40dBf
Image Reiection Ratio : 40dBf
Frequency Response : 30Hz~ 15kHz
+0.5dB/-3dB
Distortion(1kHz) :
Mono :0.4%
Stereo : 0.5%
Signal-to-Noise Ratio(at 65dBf, 1kHz) :.
Mono : 65dB
Stereo : 60dB
AM suppression Ratio : 40dB
Stereo Separation(1kHz) : 30dB
AM Section
Tuning Rane : 522kHz~ 1620kHz
(9kHz steps)[EUR/DM ]
530MHz~ 1720MHz
(10kHz steps)[T/C]
87.50MHz~ 108.00MHz
Usable Sensitivity : 55dB/m
Distortion(1kHz) : 1.5%
Signal-to-Noise Ratio : 35dB
Standard accessories
Remote control unit : 1
Operator’s m anual : 1
AM Loop Antenna : 1
FM Antenna : 1
FM Matching Transformer : 1 (T/C)
