Teac CD-P1250 - MAIN PCB PARTS LIST; DISPLAY PCB PARTS LIST; HP PCB PARTS LIST; POWER PCB PARTS LIST

MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09265600 MAINPCBASSY
9A09265700 MAINPCB
9A07152600 HEATSINK
9A09271100 SCREW,MACHINEM3X8
9A09271200 NUT,M3
CN01 9A09270400 WAFER,5P
CN02 9A09218500 WAFER,6P
CN03 9A09270500 WAFER,16P(FFC)
CN09 9A09271000 PLUG,19P
CN10 9A09270600 WAFER,2P
CN11 9A09218400 WAFER,4P
D01‑D04£ 9A09267000 DIODE,1A3‑1
D05 9A09267100 DIODE,1SS133‑T‑77
D06 9A09267200 DIODE,ZENER
D07 9A09267000 DIODE,1A3‑1
D08 9A09267300 DIODE,BAT46
E13£ 9A09270100 C,ELECT4700UF25VM
IC01 9A09188600 IC,BA5813FM
IC02£ 9A09188800 IC,KA7805
IC03 9A09270700 IC,UPD63711AGC‑8EU
IC04£ 9A09188900 IC,KA7808
JK501 9A09270900 RCAJACK,2P
OP1 9A09189500 IC,NJM4558D
Q01 9A09266700 TR,2SB1375
Q02,Q03 9A09207100 TR,2SA933AS‑TP
Q04‑Q07 9A09266800 TR,2SC2240BL
Q08 9A09266900 TR,2SD1936T‑AC
Q11‑Q13£ 9A09266800 TR,2SC2240BL
Q14 9A09207100 TR,2SA933AS‑TP
R26£ 9A09268200 R,FUSIBLE1/4W10JA
X01 9A09270800 CRYSTAL,16.9344MHZ50PPM
KEY PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09265800 KEYPCBASSY
9A09271300 KEYPCB
CN101 9A09271900 PLUG,19P
D100‑D106 9A09208100 DIODE,1SS133T77
IC01 9A09271500 IC,UPD789406AGC
S100‑S112 9A08467800 SWITCH,TACT,SKHHANA010
U100 9A09271400 IC,PST600D
U101 9A06847600 IC,GP1U281X
X100 9A09271800 CRYSTAL,5.000MHZAT‑39
DISPLAY PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09266100 DISPLAYPCBASSY
9A07154200 DISPLAYPCB
9A07149500 HOLDER,LAMP
9A07989100 LCD,IS06193P00V2
9A07989900 FILTER,LCD,BLUE
9A07990000 FILTER,LCD,WHITE
9A09272300 LAMP,PILOTC‑2V
H.P. PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A07148500 H.PPCBASSY[US,C]
9A07148510 H.PPCBASSY[E,UK]
9A07153200 H.PPCB
9A09274500 NUT,M9X0.75
9A09274600 WASHER,9.2X14X0.4
9A07078500 BRACKET‑E,JACK
IC401 9A07153300 IC,M5218AP
J401 9A07081200 JACK,H.P.
VR401 9A07082700 VR,ROTARY50K
POWER PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09266000 POWERPCBASSY[US,C]
9A07148610 POWERPCBASSY[E]
9A07148630 POWERPCBASSY[UK]
9A09272000 POWERPCB[US,C]
9A07155300 POWERPCB[E,UK]
9A09195600 HOUSING,2P
9A07081100 PLUG,ROUNDPIN
£ 9A08660100 POWERCORD[US,C]
£ 9A07087801 POWERCORD[E]
£ 9A07258200 POWERCORD[UK]
9A09345000 DIODE,6KE27CA[E,UK]
9A09345100 FERRITECORE,25X15X13[E,UK]
C01£ 9A07080700 CAPACITOR
EC01,EC02 5760663000 ECTERMINAL,1P
F01 9A07088000 FUSEHOLDER[E,UK]
F01£ 9A09251800 FUSE,250V1A[E,UK]
SW01£ 9A06849100 SWITCH,PUSH,POWER
T01£ 9A07154000 POWERTRANSFORMER
