EXPLODED VIEW-1
REF.NO. PARTSNO. DESCRIPTION REMARKS
31 9A09092400 MECHA,CD93F8NDT CEC0991004800
4501 9A09265600 MAINPCBASSY CEC0B10033200
4502 9A09265800 KEYPCBASSY CEC0B10033310
4503 9A07148500 H.PPCBASSY[US,C] CEC0B10027400
9A07148510 H.PPCBASSY[E,UK] CEC0B10027401
4504 9A09266000 POWERPCBASSY[US,C] 01‑P12500003‑00
9A07148610 POWERPCBASSY[E] CEC0B10028540
9A07148630 POWERPCBASSY[UK] CEC0B10028541
4505 9A09266100 DISPLAYPCBASSY 01‑P12500004‑00
5101 9A09266200 ESCUTCHEON[US,C] CEC2141003313
9A07148800 ESCUTCHEON[E,UK] CEC2141003310
5102 9A07148900 PANEL,TRAY CEC2155000710
5103 9A08667500 BADGE CEC2163004000
5104 9A07149100 WINDOW CEC2164006110
5105 9A07149000 BUTTON,PLAY CEC2175011810
5106 9A07077900 BUTTON,FUNCTION CEC2175011900
5107 9A07079200 FILTER,IR CEC2431001200
5110 9A07149200 DECORATION,TRAY CEC2144003910
5111 9A07077700 KNOB,ROTARY CEC2171001800
5112 9A07077800 KNOB,PUSH CEC2174005200
5116 9A07079800 SHEET,IR CEC2462011300
5120 9A07077000 COVER,TOP CEC2121003900
5121 9A09266300 PANEL,REAR[US,C] CEC2153002350
9A09272400 PANEL,REAR[E,UK] CEC2153002351
5122 9A07078400 CHASSIS CEC2311006900
5123 9A06842900 ASSY,LEG CEC0251001700
5124 9A07078300 LEG CEC2251003500
5130 9A07078800 JOINT CEC2351001900
5131 9A07078900 POST CEC2373001100
5132 9A07989100 LCD,IS06193P00V2 CEC4T40000500
5133 9A07149500 HOLDER,LAMP CEC2451001300
5134£ 9A06846200 BUSHING,NIFCO2271 CEC2446000200
5135 9A07989900 FILTER,LCD,BLUE CEC2431001301
5136 9A07990000 FILTER,LCD,WHITE CEC2431001302
5141 9A07078700 BRACKET‑M,TOP CEC2322001800
5142 9A07274200 FELT,PL CEC2571002200
CN01 9A09195600 HOUSING,2P 43‑791002031‑00
PC120£ 9A08660100 POWERCORD[US,C] CEC4W10006400
£ 9A07087801 POWERCORD[E] 45‑112230118‑06
£ 9A07258200 POWERCORD[UK] CEC4W10004700
T01£ 9A07154000 POWERTRANSFORMER CEC4L50005930
51SA1 9A06855600 SCREW,S‑TPGBIN2.6X6 SFBDN266R0SE‑
51SB1 9A00768400 SCREW,S‑TPGBRZM2.6X8 SFBAN268R0SE‑
51SB2 9A00768400 SCREW,S‑TPGBRZM2.6X8 SFBAN268R0SE‑
51SC1 9A01589800 SCREW,S‑TPGBINM3X6 SFBDN306R0SE‑
51SC2 9A01589800 SCREW,S‑TPGBINM3X6 SFBDN306R0SE‑
51SD1 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD2 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD3 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD4 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD5 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD6 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SD8 9A01041200 SCREW,S‑TPGBINM3X8 SFBDN308R0SM‑
51SE1 9A07086400 SCREW,S‑TPGBIN3X14 SFBDN30140SE‑
51SF1 9A07086500 SCREW,S‑TPGBIN3X25 SFBDN30250SE‑
51SG1 9A06856000 SCREW,S‑TPGTRS4X6 SFSTN406R0SE‑
51SI1 9A06855700 SCREW,S‑TPGBIN3X4 SFBDN304R0SE‑
