1 SPECIFICATIONS
−2−
CD PLAYER
Pickup:
3-beam, semiconductor laser
D/A Converter:
1 bit DAC
Digital filter:
8-times oversampling
Frequency Response:
20 Hz ~ 20 kHz ±1.5dB
Total Harmonic Distortion:
< 0.02 % (1 kHz)
Signal-to-Noise Ratio (S/N):
>85 dB (1 kHz)
Channel Separation:
>80 dB (1 kHz)
Output:
Analog; 2.0 Vrms (RCA)
Digital; TOS OPTICAL
Wow and Flutter:
Below measurable limit
GENERAL
Power Requirements:
230 VAC, 50Hz (UK/Europe Model)
240 VAC, 50Hz (Australia Model)
Power Consumption:
12 Watts (AC)
Dimensions (W x H x D):
435 x 104 x 290mm
(17-1/8" x 4-1/8" x 11-7/16")
Net Weight:
3.6 kg
Standard Accessories:
Wireless Remote Control Unit (RC-682)
RCA pin-plug cord
Battery (SUM-3, "AA", "R6" type) x 2
• Design and specifications are subject to change without notice.
CONTENTS
1 SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2 EXPLODED VIEWS AND PARTS LIST
・・・・・・・・・・・・・・・・・・・・・・3
3 PC BOARDS AND PARTS LIST
・・・・・・・・・・・・・・・・・・・・・・・・・・・・7
4 INCLUDED ACCESSORIES
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・11
5 BLOCK DIAGRAM
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・12
NOTES
●
PC boards shown are viewed from parts side.
●
The parts with no reference number or no parts number in the
exploded views are not supplied.
●
As regards the resistors and capacitors, refer to the circuit diagrams
contained in this manual.
●
£ Parts marked with this sign are safety critical components. They
must be replaced with identical components - refer to the
appropriate parts list and ensure exact replacement.
●
Parts of [ ] mark can be used only with the version designated.
[E]:EUROPE[UK]:U.K.
