Teac DR-H300 - Amplifier PCB Assembly Parts; Headphone PCB Assembly Parts; Speaker Output PCB Assembly Parts

REF. NO
PARTS NO.
DESCRIPTION
AMP PCB ASSY
05-DRH300-03A101
AMP PCB ASSY
REMARKS
DR-H300
35-DRH300-03AI
AMP PCB
!
11
L302,313
15000019
FIXED INDUCTOR 22U
C332,333
14000361
E.CAP 4700UF/35V
DZ301
16000070
ZENER DIODE 5.6V
Q301,309
17000005
CHIP TR - BC817-25
Q302
17000013
TR - 2SB772A
BD301
18000009
THYRISTOR - RS808
IC302
19000112
IC - 7812
IC303
19000120
IC - TDA8920
CN301
25000020
PIN CONNECTOR 3.95MM 3PIN
CN305
25000029
PIN CONNECTOR 2.5MM 4PIN
CN302
25000053
PIN CONNECTOR 2MM 9PIN
F301,302
26000009
FUSE F6.3AL250V
L305,310
33000017
FERRITE BEAD JRHW0349 -BLUE
!
HEADPHONE PCB ASSY
REF. NO
DESCRIPTION
PARTS NO.
05-DRH300-05A101
HEADPHONE PCB ASSY
HEADPHONE SOCKET #TE-03501S-05
CN502
25000025
35-DRH300-05A1
HEADPHONE PCB
REMARKS
J104
24000120
HEADPHONE SOCKET #TE-03501S-11
CN501
25000014
PIN CONNECTOR 2MM 3PIN
JACK202
24000177
PIN CONNECTOR 2MM 4PIN
SPEAKER OUTPUT PCB ASSY
REF. NO
PARTS NO.
SPEAKER OUTPUT PCB ASSY
05-DRH300-07A101
DESCRIPTION
PINS CONNECTOR 2.5MM 4PIN
25000029
REMARKS
SPEAKER OUTPUT PCB
35-DRH300-07A1
CN701
SPK701
24000288
SPEAKER SOCKET 4PIN
