Teac DR-H300 - CPU PCB Assembly Parts

CPU PCB ASSY
REF. NO
PARTS NO.
DESCRIPTION
05-DRH300-02A101
REMARKS
CPU PCB ASSY
35-DRH300-02A1
CPU PCB
9
DR-H300
L202
15000005
FIXED INDUCTOR 10u #52
L203,204
33000038
FERRITE BEAD CBG0805 2.2K
X201
22000027
CRYSTAL 4.332MHZ
X202
22000018
CER.FILTER 4.19MHZ
C259
14000296
E.CAP 3300UF/35V
D205
16000128
CHIP DIODE 4148
DZ202
16000070
ZENER DIODE 5.6V
DZ203
16000077
ZENER DIODE 9.1V
DZ201
16000089
ZENER DIODE 27V
D213 16000115
DIODE 1N60
D212,214-217
16000018
DIODE 4148
D101-105,202,
D204
16000104
RECTIFIER DIODE 4001
Q204,208
17000009
CHIP TR - 9014
Q101,207,209
17000025
TR - 8050C
Q205,206
17000030
TR - 8550C
Q202,203
17000034
TR - 9014C
Q201
17000039
TR - 9015C
BD201
18000007
THYRISTOR - RS406
IC205
IC - PT2314
IC206
19000079
19000075
IC - PT2309-S
IC204
19000071
IC - AT24C02-PC27
IC201,203
19000103
IC - LM7805
IC202
19000169
CPU - U252(3P9228)
X203
22000021
CRYSTAL 32.768KHZ
CN201
25000059
PINS CONNECTOR 2MM 11PIN
CN211
25000014
PIN CONNECTOR 2MM 3PIN
CN203,209,210
25000025
PIN CONNECTOR 2MM 4PIN
CN202
25000034
PIN CONNECTOR 2MM 5PIN
CN204
25000044
PIN CONNECTOR 2MM 7PIN
CN205,206
25000053
PIN CONNECTOR 2MM 9PIN
CN208
25000016
PIN CONNECTOR 2.5MM 3PIN
CN207
25000046
PIN CONNECTOR 2.5MM 7PIN
JACK201
24000080
RCA SOCKET 4PIN
JACK203
24000115
SINGLE RCA SOCKET
F202,203
26000083
FUSE F1A/125V
F201
26000002
FUSE F2AL250V
!
!
!
IC208
19000087
IC - PT2579-SN
L201
15000007
FIXED INDUCTOR 10u
