– 22 –
(Fig.14.4-7) Ultra DMA transfer timing (Data in burst) (Fig. 3 of 3)
Symbol Item Min Max Unit
t50 Unlimited interlock time 0 ns
t51 Setup time/Hold time (to –DMACK ↓ )20 ns
t52 Envelope time (–DMACK ↓ to STOP/
–HDMARDY ↓ )
20 70 ns
t53 DSTROSE negate start time (STOP/–HDMARDY
↓ to DSTROBE ↓ )
0170ns
t54 DSTROBE drive delay time (to –DMACK ↓)0 ns
t55 Output data, release delay time (to –DMACK ↓)10ns
t56 Output data, drive start time (to STOP ↓/
–HDMARDY ↓)
0ns
t57 Valid data, setup time (to DSTROBE edge) 30 ns
t58 Valid data, hold time (to DSTROBE edge) 6 ns
t59 DSTROBE cycle time Mode 2 54 ns
Mode 1 73 ns
Mode 0 112 ns
t60 DSTROBE x 2-cycle time Mode 2 115 ns
Mode 1 154 ns
Mode 0 230 ns
DSTROBE Average x 2-cycle time Mode 2 120 ns
Mode 1 160 ns
Mode 0 240 ns
t61 DSTROBE stop shift time (DSTROBE
edge to –HDMARDY ↑)
Mode 2 20 ns
Mode 1 30 ns
Mode 0 50 ns
t62 Final DSTROBE stop time (to –HDMARDY ↑)60ns
t63 DSTROBE ↑ to –DMACK ↑ delay time 20 ns
t64 Limited interlock time 0 150 ns
t65 DSTROBE release time (to –DMACK ↑)20ns
t66 DSTROBE edge to HDMARQ ↓ delay time 50 ns
t67 HDMARQ ↓ to CRC data output delay time 20 ns
t68 Data setup time (to –DMACK ↑)30ns
t69 Data hold time (to –DMACK ↑)6ns
