Teac GF-680 - Timer Recording; Display

29
ENGLISH
Timer Recording
Set the start time and stop time (see 27 page).
Load a recordable cassette tape into TAPE
@.
2
1
Select a source to be recorded by pressing the corresponding
button.
3
< Don’t select "TAPE".
<
When you select "TUNER", tune in a station.
Press the TIMER button.
4
"TIMER" indicator appears on the display.
Press the POWER switch to turn the unit off(standby).
5
Press the RECORD button of TAPE @.
6
5
6
3
2
4
Display
Each time the DISPLAY button is pressed, the display is changed
as follows:
During playback of CD:
When the unit is on:
"clock", "timer on" or "timer off" is displayed for 5 seconds, and
then returns to "source".
When the unit is off:
"timer on" or "timer off" is displayed for 5 seconds, and then
returns to "clock".
elapsed time of
the current track
remaining time
of the disc
timer off timer on clock
(source) clock
timer off timer on
TIMER
ON OFF
STEREO
CLASSIC
ROCK
POPS
FLAT
PLAY
MHz
kHz
2
1
3
