Teac LE1978HD - Back View Connection Ports

DC POWER IN(DC 12V 5A)
1 5
HEADPHONE OUT
9
HDMI
USB
2 6
RF
10
VGA(D-Sub 15PIN)
3
AV1
AV2
7
COAX OUT
11
PC AUDIO IN
8
YPbPr˄Component˅
4
Power Connecting
1. Connect the small round plug on the power adaptor cable to the power
input socket at the rear of the set.
2. Connect the mains cable between the power adaptor and the mains supply.
Power adaptorMains cable
L-in
AV 2
R-in
L-in
AV 1
R-in
1 2 3 4 5 6 7
10
9
11
8
USB
Component
Component
8
General Description
Back View
