16
Listening to a Record
< Before use, completely loosen the transportation screw by
turning it clockwise with a coin and remove the stylus guard.
1
Press the PHONO/TAPE/AUX button once or twice to select
PHONO.
2
Gently open the dust cover.
< When opening the cover, pay attention to prevent your hand
from getting caught.
3
Put the record on the turntable.
When playing a 45 RPM large hole single record, use the included
adaptor.
4
Select the speed.
5
Gently push the clamper to the right to release the tone
arm.
clamper
6
Raise the cue lever to lift the tone arm off the tone arm
support.
tone arm
cue lever
transportation screwadaptor
To Next Page
