ENGLISH
Specifications Messages
TRACK
0 0:00
A blank CD-R/CD-RW disc has been loaded.
BUSY
The unit is reading the disc. Wait a few seconds.
CLOSE
Close the disc tray.
ERASE
Erase the last track of the CD-RW disc.
ERASEALL
Erase all the tracks of the CD-RW disc.
FINAL
Finalize the disc.
–40db, –30db or –20db
Settings of the track number assignment mode
NO DISC
No readable disc has been loaded.
OPEN
Open the tray.
- - - -:- -
The unit is reading the disc.
P-**
Program number
UNFINAL
Unfinalize the CD-RW disc.
Error Messages
DISCFULL
There is no space on the disc, or no more tracks are available.
P FULL
32 tracks have been programmed. No more tracks can be
programmed.
ERR **
An error occurred within the unit.
Press the POWER switch to turn the unit off, wait a minute, and
turn it on again.
DISC ERR
An error disc or irregular-shaped disc has been loaded.
DAO DISC
The unfinalize function cannot be performed with discs recorded
using the "Disc at Once (DAO)" recording system.
d disc
A CD disc other than Audio CD (Video CD, MP3, Data CD etc.) has
been loaded.
(** is variable.)
Amplifier Section
Output power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 W + 3.5 W
Frequency response . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Hz to 20 kHz
Audio input sensitivity/Impedance . . . . . . . . . . . .AUX: (0.5 V)/20 kΩ
CD Recorder Section
Media type . . . . . . . . . . . . . . . . . . . CD-RW and CD-R for Digital audio
(record and playback)
CD (playback only)
Recording sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . 44.1 kHz
Frequency response . . . . . . . . . . . . . . . . . . . . 20 Hz to 20 kHz (±3 dB)
Signal to noise ratio . . . . . . . . . . . . . . . . . More than 85 dB (playback)
More than 75 dB (recording)
Cassette tape section
Tracking system . . . . . . . . . . . . . . . . . . . . . . . . 4-track, 2-channel stereo
Tape speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.8 cm/sec
Wow&flutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3%
Frequency characteristic . . . . . . . . . . . . . . . . . . . . . . . .125Hz to 10 kHz
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 dB
Tuner Section
Frequency range (FM) . . . . . . . . . . . . . . . . . . . . 87.5 MHz to 108.0 MHz
Frequency range (AM)
North American Model . . . . . . . . . . . . . . . . . . 530 kHz to 1,720 kHz
European Model . . . . . . . . . . . . . . . . . . . . . . . . . 522 kHz to 1,629 kH
Record Player Section
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC servo motor
Drive system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Belt Drive
Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-1/3 rpm, 45 rpm, 78 rpm
Wow and Flutter . . . . . . . . . . . . . . . . . . . . . . . . . . . less than 0.3% (WDT)
Signal to noise ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . More than 50 dB
Cartridge type . . . . . . . . . . . . . . . . . . . . . . . . .Ceramic Stereo Cartridge
Stylus . . . . . . . . . . . . . . . . . . STL-103 (premounted) / SPL-102 (option)
Output level . . . . . . . . . . . . . . . . . . . . . 158 - 348 mV (50 mm/S, 1 kHz)
Speaker System Section
Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76 mm (3”)
Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 ohms
GENERAL
Power requirements
North American Model . . . . . . . . . . . . . . . . . . . . . . . . . . 120 V, 60 Hz
Europe model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230 V, 50 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 W
Dimensions (W x H x D) . . . . . . . . . . . . . . . . . . . . .470 x 230 x 390 mm
(18 1/2” x 9 1/16” X 15 3/8”)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 kg (24 1/4 lb)
Operating temperature range . . . . . . . . . . . . . . . . . . . . . . . 5°C to 35°C
Accessories
Owner’s manual FM antenna
Warranty card AM antenna
Quick Start Guide for recording Turntable cover
45 RPM adaptor Stereo RCA pin cable
Remote control unit (RC-1258) Hinge x 2
Battery (AA, alkaline or MN) x 2
< Design and specifications are subject to change without notice.
< Weight and dimensions are approximate.
< Illustrations may differ slightly from production models.
