Teac SL-D910 - Printed Circuit Board Assemblies and Parts; Main PCB Assembly Details

19
SL-D910
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-D9101010-R MAIN PCB ASS'Y
062-SD910001-R MAIN PCB 94V-0 REV:01 241MM×108MM
C9,C12 072-30470251-R E/C CAP 4700UF/25V M (H≤30MM
）
C10 072-30100161-R E/C CAP 1000UF/16V M (
10×12MM)
C64,67,68 072-30100251-R E/C CAP 1000UF/25V M (H≤22MM)
CN1 082-20400100-R CONNECTOR 4PIN P=2.5MM
CN2 082-10340100-R CONNECTOR 3PIN P=2.5MM
CN3 082-10300100-R CONNECTOR 3PIN P=2.0MM
CN4 082-10240100-R CONNECTOR 2PIN P=2.5MM
CN6 082-20500100-R CONNECTOR 5PIN P=2.0MM
CN7 082-20950100-R FPC CONNECTOR 9PIN P=1.25MM
CN10 082-20300100-R CONNECTOR 3PIN P=2.0MM
CN11,12 082-20540100-R CONNECTOR 5PIN P=2.5MM
D1,2,3,4 077-10539201-R DIODE 1N5392 DC
D5,6,7,8 077-10400201-R DIODE 1N4002 DC
D10,11,12,13 077-00414801-R DIODE F4148
FUSE01,02 090-22520022-R FUSE T2AL 250V “UL/CSA/VDE”MARK
IC1 075-00231429-R IC:PT2314
IC3 075-00780801-R IC:AN7808
IC4 075-00780501-R IC:KIA7805API 618
IC5,6 075-00455808-R IC:BA4558 553 H15
IC7 075-00821841-R IC:TA8218AHQ 688KAI
L2.L3.L4. 052-SRL50010-R HORIZONTAL FERRITE CORE
L8 078-05301952-R FILTER COIL
0.5MM× 3.0MM×19.5T
L9 052-SRL50020-R UPRIGHT FERRITE CORE
L11
Q1,2,5,8,12,13, 076-00C94500-R TRANSISTOR:C945 QCG10
Q14,15,16,17,18
Q3,11 076-C2001L00-R TRANSISTOR:C2001 L63E
Q6 076-00A73300-R TRANSISTOR:A733 QCF45
Q7 076-00B54400-R TRANSISTOR:B544 F6C
ZD1 077-3012A20H-R ZENER DIODE 12V 0.5W
ZD2 077-3004C30H-R ZENER DIODE 4.3V 0.5W
ZD3
MAIN PCB ASSY
5 PC BOARDS AND PARTS LIST
