Teac SL-D910 - CD PCB Assembly Details; Control PCB Assembly Details

23
SL-D910
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-D9101030-R CD PCB ASS'Y
062-SD910002-R CD PCB FR-4 PLY=1.0MM REV:00 132MM×112MM
CN201 082-20600100-R CONNECTOR 6PIN P=2.0MM
CN202 082-21600305-R FPC CONNECTOR 16PIN P=1.0MM
CN203,204 082-20400100-R CONNECTOR 4PIN P=2.0MM
CN205 082-20600200-R CONNECTOR 6PIN P=2.0MM (BROWN)
CN206 082-20950100-R FPC CONNECTOR 9PIN P=1.25MM
CN207 082-20300100-R CONNECTOR 3PIN P=2.0MM
CN208 082-21150100-R FPC CONNECTOR 11PIN P=1.25MM
D201,202,203 077-00414801-R DIODE F4148
L201,204 052-SRL50010-R HORIZONTAL FERRITE CORE
L205,206 052-08356001-R HORIZONTAL FERRITE CORE:
0.8× 3.5×6MM
L208,209,210 095-10100001-R INDUCTOR 100UH 0.5W
L308 052-SRL50010-R HORIZONTAL FERRITE CORE
IC201 075-86FS4931-R IC:TMP86FS49AUG
IC202 075-00688839-R IC:OTI 6888-G
IC203 075-27B51239-R IC:AT27BV512
IC204 075-94A77F31-R IC:TC94A77FG-203
IC206 075-S3001192-R IC:AUK S30011
Q201,202,203 076-00A73300-R TRANSISTOR:A733 QCF45
XT202 093-07372802-R XTAL 7.3728MHZ
XT204 093-11431802-R XTAL 14.318MHz
CD PCB ASSY
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-D9101020-R CONTROL PCB ASS'Y
062-SD910004-R FRONT CONTROL PCB 94-HB REV:00 128MM×112MM
CN601 082-21150100-R FPC CONNECTOR 11PIN P=1.25MM
IC601 075-HT162139-R IC:HT1621B(SSOP-A)
LCD1 080-SD910021-R LCD DISPLAY SIZE
:76×24MM
LED601,602 094-03020301-R LED:
3MM
Q601 076-00C94500-R TRANSISTOR:C945 QCG10
U601 083-00LT1000-R RECIVE SENSOR <PIC-2031 SMB/F22>
SW601,602,603, 063-0GP28020-R TACT SW. H=5.0MM
SW604,608,609,
SW610,611,612,
SW613,616,617,
SW618
SW605,606, 063-D2800020-R TACT SW. SKHHALM
SW614,615
SW607 063-SRL35090-R TACT SW. H=5.5MM
CONTROL PCB ASSY
