Teac SL-D910 - Tuner PCB Assembly Details

21
SL-D910
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-D9101040-R TUNER PCB ASS'Y
062-SD910003-R TUNER PCB 94V-0 REV:00 100MM×94MM
CN401 082-20700100-R CONNECTOR 7PIN P=2.0MM
CN402 082-10240100-R CONNECTOR 2PIN P=2.5MM
D401,402,403, 077-00414801-R DIODE F4148
D404,405,406,
D407,408
IC401 075-TA209901-R IC:TA2099N
IC402 075-00257929-R IC:PT2579-SN
IC403 075-09257F21-R IC TC9257F
L401 079-D2800011-R AM IFT COIL YELLOW (3A007C)
L402 079-D2930210-R AM OSC COIL 3M005 RED
L405 096-SD910010-R AM BAR ANT COIL 80T:25T
L406,407 095-10100001-R INDUCTOR 100UH 0.5W
L408,409 095-00470001-R INDUCTOR 47uH 0.5W
Q402,407 076-09018H00-R TRANSISTOR:9018H
Q401,403,405 076-00C94500-R TRANSISTOR:C945 QCG10
Q406,408,409,
Q410,411,412
Q404,413 076-00A73300-R TRANSISTOR:A733 QCF45
CF401,402 081-31070201-R FM CERAMIC FILTER, L10.7MA5-A 3PIN
CF403 093-11070005-R CERAMIC FILTER CDA10.7MG82 2PIN
CF404 081-04500000-R AM CERAMIC FILTER, SFU450B 3PIN
TC401 073-00010022-R TC.10PF
XT401 093-04332002-R XTAL 4.332MHz
XT402 093-07200002-R XTAL 7.2MHZ
X401 054-0GP18000-R FM ANT FILTER GFMB3 <76-108MHZ>
VD401,402 077-50014901-R 1SV149 (TOSHIBA)
CW402
ZD401 077-3005C20H-R ZENER DIODE 5.1V 0.5W
ZD402 077-3005B20H-R ZENER DIODE 4.7V 0.5W
ZD403 077-3009A20H-R ZENER DIODE 7.9-8.3V 0.5W
TUNER PCB ASSY
