25
SL-D910
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-90MU1050-R BASS VR PCB ASS'Y
062-SD910005-R BASS PCB 94-HB REV:00
CN9 082-10300100-R CONNECTOR 3PIN P=2.0MM
VR1 069-SD901000-R
VR:50KB+C <RA0901N0XOA-VA1-B503-T1-FA125B070>
BASS PCB ASSY
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-90MU1080-R SNOOZE PCB ASS'Y
062-SLD90004-R SNOOZE PCB
SW019,021 063-SLD90000-R TACT SW. H=4.3MM
SW020 063-SLD90001-R TACT SW. H=5.0MM
SNOOZE PCB ASSY
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-90MU1070-R HEAD PHONE JACK PCB ASS'Y
062-90MP3008-R HEAD PHONE JACK PCB 94-HB REV:00
JK01 064-35020101-R HEAD PHONE JACK
3.5MM
L504,505,506 052-D9000020-R HORIZONTAL FERRITE CORE
PHONE JACK PCB ASSY
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-90MU1060-R CD SWITCH PCB ASS'Y
062-SLD90004-R CD SWITCH PCB
SW022 063-SLD80400-R CD DOOR ON/OFF SW.
SW023 063-SLD80800-R TACT SWITCH H=7.5MM
CD SW PCB ASSY
REF.NO TEAC PARTS NO. PARTS NO. DESCRIPTION REMARKS
100-90MU1100-R AUX JACK PCB ASS'Y
062-90MP3006-R AUX JACK PCB 94-HB REV:00
L501,L502,L503 052-D9000010-R HORIZONTAL FERRITE CORE
JK1 064-35020002-R AUX JACK
3.5MM
AUX JACK PCB ASSY
